African Energy modules are made by some of the world’s most sophisticated module manufacturers and are designed for Africa’s off-grid solar charging and water pumping needs. The modules include efficient crystalline cells set in a solid aluminum frame and feature TÜV and IEC certification. With a 30-year warranty, these modules can provide power for several generations – and the quality is assured by African Energy’s decade of experience in the solar industry.

Electrical Characteristics:

• Maximum Power at STC (Pmax) 620 W
• Optimum Operating Voltage (Vmp) 40.93 V
• Optimum Operating Current (Imp) 12.90 A
• Open Circuit Voltage (Voc) 48.40 V
• Short Circuit Current (Isc) 13.70 A
• Module Efficiency 22.95%
• Operating Module Temperature -40 °C to +85 °C
• Maximum System Voltage 1000/1500 V DC (IEC)
• Maximum Series Fuse Rating 20 A
• Power Tolerance 0/+5 %
• 30-year warranty

Mechanical Specifications:

• Solar Cells Monocrystalline 144 (72*2) pcs
• No. of Cells 144 (72*2)
• Dimensions 2278x1134x30mm
• Weight 28.3kg
• Front Glass High transparency solar glass 3.2mm
• Frame Black/Silver Anodized aluminum alloy
• Junction Box IP68 rated
• Output Cables 4.0 mm2, portrait: 300mm/300mm
• Connector MC4 Compatible
• Wind/Snow Load 2400pa/5400pa

Key Features

• N-type TechnologyN-type modules with Tunnel Oxide Passivating Contacts (TOPcon) technology offer lower LID/LeTID degradation and better low light
  performance.
• HOT 3.0 TechnologyN-type modules with Jinko Solar’s HOT 3.0 technology offer better reliability and efficiency.
• Durability Against Extreme EnvironmentHigh salt mist and ammonia resistance.
• Mechanical Load EnhancedCertified to withstand:
  5400 Pa front side max static test load
  2400 Pa rear side max static test load.
• SMBB TechnologyBetter light trapping and current collection to improve module power output and reliability.
• Anti-PID GuaranteeMinimizes the chance of degradation caused by PID phenomena through optimization of cell production technology and material
  control.

Specification | STC

• Module Type: JKM615N-66HL4M-V
• Maximum Power (Pmax): 615Wp
• Maximum Power Voltage (Vmp): 40.73V
• Maximum Power Current (Imp): 15.10A
• Open-circuit Voltage (Voc): 48.79V
• Short-circuit Current (Isc): 16.08A
• Module Efficiency STC (%): 22.77%
• Temperature Coefficients of Pmax: -0.29 %/°C
• Temperature Coefficients of Voc: -0.25 %/°C
• Temperature Coefficients of Isc: 0.045 %/°C
• Power tolerance: 0~+3%
• Operating Temperature: -40 °C ~ +70°C
• Maximum System Voltage: 1000/1500 VDC (IEC)
• Maximum Series Fuse Rating: 30 A

Mechanical Characteristics

• Cell Type: N -type Mono-crystalline
• No. of cells: 132 (66×2)
• Dimensions: 2382×1134×35 mm
• Weight: 28.2 kg
• Front Glass: 3.2mm, Anti-reflection Coating, High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminum Alloy
• Junction Box: IP68 Rated
• Protection Class: Class II
• IEC Fire Type: Class C
• Connector Type: K03M/MC4/Others
• Output Cables: 4.0 mm2 (+): 400 mm, (-): 200 mm or Customized Length

14-inch diagonal, Full HD (1920 x 1080) IPS display,Intel Celeron N4020 processor4GB DDR4-2400 MHz RAM,500GB SATA HDD,Intel UHD Graphics 600,1x USB 3.2 Gen 1 Type-A port,1x HDMI port,1x headphone/microphone combo jack,1x RJ45 Gigabit Ethernet port,802.11ac Wi-Fi,Bluetooth 4.2,FreeDOS

Universal power measurement for intelligent energy measurement

A high-performance measurement solution for intelligent energy management in PV systems with SMA devices. The SMA Energy Meter calculates phase-exact and balanced electrical measured values and communicates these via Ethernet in the local network. In this way, all data on grid feed-in and purchased electricity as well as PV generation by other PV inverters can be communicated to SMA systems frequently and with a high level of precision.

Integrating the SMA Energy Meter establishes, in all systems, an ideally coordinated system configuration that guarantees the highest performance and stability with the best cost savings and increased self-consumption.
