Higher yields / Safe & Reliable / Smart / User-friendly

SUN-20K-SG05LP3-EU-SM2 is a brand new three-phase hybrid inverter with a low-voltage battery, ensuring the system is safe and reliable. With a compact design and high-power density, this series supports a 1.3 DC/AC ratio, saving device investment. It supports a three-phase unbalanced output, extending the application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remote control, and x1 DRM port, which makes the system smart and flexible.

It is equipped with RS485 / CAN port for battery communication.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely, which makes PV plant O&M easier.

Key Features

• 100% unbalanced output, each phase; Max. output up to 50% rated power
• AC couple to retrofit existing solar system
• Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
• Max. charging/discharging current of 350A
• Support storing energy from diesel generator
• 48V low voltage battery, transformer isolation design
• 6 time periods for battery charging/discharging

Technical Specifications

Mechanical Characteristics

• Solar Cell: Monocrystalline silicon 182 mm
• No. of Cells: 144 (6 × 24)
• Dimensions: 2278 × 1134 × 35 mm (89.7 × 44.6 × 1.4 inches)
• Weight: 27.5 kgs (60.6 lbs.)
• Front Glass: 3.2 mm (0.126 inches) fully tempered glass
• Output Cables: 4.0 mm2, (-) 350 mm (+) 160 mm in length or customized length
• Junction Box: IP68 rated (3 bypass diodes)
• Operating Module Temperature: -40 °C to +85 °C
• Maximum System Voltage: 1500 V DC (IEC)
• Maximum Series Fuse Rating: 25 A
• Power Tolerance: 0/+5 Wc

Electrical Characteristics

• Module Type: STP555S-C72/Vmh
• Testing Condition: STC
• Maximum Power (Pmax/W): 555
• Optimum Operating Voltage (Vmp/V): 42.24
• Optimum Operating Current (Imp/A): 13.14
• Open Circuit Voltage (Voc/V): 50.07
• Short Circuit Current (Isc/A): 14.07
• Module Efficiency (%): 21.5

The 5K3 XP is the most advanced Lithium Module for Home and Industrial Energy Storage systems. One product suitable for two applications LV and HV. Fast connections. Wall Mounted, floor mounted, Stackable, serial or parallel application. High Capacity thanks to expandible and simple configuration. Wireless monitoring for real time intervention and maintenance.

LOW VOLTAGE AND HIGH VOLTAGE

SINGLE MODULE:

• Model: GW120K-HT
• Max. Input Voltage (V): 1100
• MPPT Operating Voltage Range (V): 180 ~ 1000
• Start-up Voltage (V): 200
• Nominal Input Voltage (V): 600
• Max. Input Current per MPPT (A): 30
• Max. Short Circuit Current per MPPT (A): 45
• Number of MPPTs: 12
• Number of Strings per MPPT: 2

The HT 1100 Vdc Series 73-120 kW is GoodWe’s new string inverter for C&I and small utility projects to boost your power and profit. Generate your solar power and make use of it with this centerpiece of the clean energy system. The HT Series seamlessly incorporates its technical strengths designed to achieve higher savings in the installation, enhance productivity with increased energy yields, realize high power density and diversify available monitoring options. It takes safety to the top possible level in accordance with the strictest industry standards and runs efficiently even under the harshest environmental conditions. This unrivalled set of features was conceived to ensure the lowest levelized cost of electricity (LCOE) to offer this ideal choice for commercial and industrial PV systems.
