S6-EH3P15K02-NV-YD-L series three-phase hybrid inverter is suitable for large residential PV energy storage systems with low battery voltage (48V). The products are compatible with high-power PV panels, and suitable for a variety of brands’ lithium and lead-acid batteries. In addition, the product has a wealth of features, including compatible generators, UPS level switching, grid-tied PV system coupling networking, supporting three-phase unbalanced load and half-wave load, etc. Helps households easily achieve zero carbon energy needs.

Three-Phase Low Voltage Energy Storage Inverter

Leading Features

• Built-in control for SG-ready heat pumps
• 7-inch LCD screen for an intuitive user experience
• Bluetooth app support for quick and easy setup
• Compatible with mainstream lithium and lead-acid batteries
• 160% PV input capacity to maximize solar energy utilization
• Easily expand system capacity using parallel connections and AC coupling
• AI intelligently manages charging and discharging based on TOU (Time-of-Use) tariffs
• Seamless integration with VPP and EMS platforms for enhanced energy optimization
• Supports three-phase unbalanced output, allowing up to 50% of rated inverter power per phase

Key Features

• N-type TechnologyN-type modules with Tunnel Oxide Passivating Contacts (TOPcon) technology offer lower LID/LeTID degradation and better low light
  performance.
• HOT 3.0 TechnologyN-type modules with Jinko Solar’s HOT 3.0 technology offer better reliability and efficiency.
• Durability Against Extreme EnvironmentHigh salt mist and ammonia resistance.
• Mechanical Load EnhancedCertified to withstand:
  5400 Pa front side max static test load
  2400 Pa rear side max static test load.
• SMBB TechnologyBetter light trapping and current collection to improve module power output and reliability.
• Anti-PID GuaranteeMinimizes the chance of degradation caused by PID phenomena through optimization of cell production technology and material
  control.

Specification | STC

• Module Type: JKM615N-66HL4M-V
• Maximum Power (Pmax): 615Wp
• Maximum Power Voltage (Vmp): 40.73V
• Maximum Power Current (Imp): 15.10A
• Open-circuit Voltage (Voc): 48.79V
• Short-circuit Current (Isc): 16.08A
• Module Efficiency STC (%): 22.77%
• Temperature Coefficients of Pmax: -0.29 %/°C
• Temperature Coefficients of Voc: -0.25 %/°C
• Temperature Coefficients of Isc: 0.045 %/°C
• Power tolerance: 0~+3%
• Operating Temperature: -40 °C ~ +70°C
• Maximum System Voltage: 1000/1500 VDC (IEC)
• Maximum Series Fuse Rating: 30 A

Mechanical Characteristics

• Cell Type: N -type Mono-crystalline
• No. of cells: 132 (66×2)
• Dimensions: 2382×1134×35 mm
• Weight: 28.2 kg
• Front Glass: 3.2mm, Anti-reflection Coating, High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminum Alloy
• Junction Box: IP68 Rated
• Protection Class: Class II
• IEC Fire Type: Class C
• Connector Type: K03M/MC4/Others
• Output Cables: 4.0 mm2 (+): 400 mm, (-): 200 mm or Customized Length

Introducing the S6-EH3P50K-H Series. High voltage, three-phase energy storage for commercial applications. The inverter series, which boasts a maximum charge/discharge current of 70A+70A across two independently controlled battery ports, has four integrated MPPTs with a string current capacity of up to 20A – ensuring unmatched power delivery. Whether for on or off-grid applications, the S6-EH3P50K-H series supports parallel operation of up to six units, with a backup port capable of supporting 1.6 times overload for short durations. This latest range is compatible with an array of batteries, thanks to its wide voltage range, and offers peak shaving control in both “self-use” and “generator” modes.

Three-Phase High Voltage Energy Storage Inverter

Leading Features

• 2 seconds of 160% overload capability
• Supports peak shaving features in “self-use” and “generator” modes
• Supports Unbalanced and Half-Wave Loads on both the Grid and Backup Port
• Supports 200% DC/AC ratio and makes full use of PV charging, providing a long backup
• Supports a maximum input current of 20A, making it ideal for all high-power PV modules of any brand
• Real-time battery monitoring, remote upgrade, and battery healing function to prolong battery life
• A wide battery voltage range accommodates the prevalent high-voltage lithium batteries found in the market
• Battery charging/discharging current 140A/70A+70A, suitable for 280Ah cell standard 0.5C application condition

DEYE 5 kW Single Phase 2 MPPT Hybrid Inverter
Colorful touch LCD, IP65 protection degree
AC couple to retrofit existing solar system
Max. 16 pcs parallel for on-grid and off-grid
operation; Support multiple batteries parallel
Max. charging/discharging current of 190A
6 time periods for battery charging/discharging
Support storing energy from diesel generator
