BOS-A is a high-performance embedded LiFePO4 battery module that offers quick installation and maintenance. With advanced safety features, intelligent BMS and eco-friendly design, it is an ideal choice for power backup and renewable energy storage. BOS-A is the ultimate solution for small-scale commercial and industrial energy storage systems (ESS). Designed for efficiency and reliability, this advanced battery system caters to a variety of power management needs while providing a sustainable energy solution.

Key Features:

• High Performance: With a capacity of 7.68 kWh and the potential for >6000 cycles, the BOS-A guarantees long-lasting energy support, ensuring that your operations run smoothly without interruptions.
• Intelligent Management: Equipped with smart cloud-based monitoring, the BOS-A enables real-time tracking of your energy consumption and battery status, optimizing performance and lowering electricity bills.
• Flexible Configuration: Capable of supporting multiple racks with up to 13 battery modules in series, this system provides adaptability to meet your growing energy demands.
• Effortless Installation: The lightweight design, at just 70 kg per module, paired with a detailed user manual, ensures a straightforward installation process.
• Safety First: Featuring an intelligent battery management system (BMS) and comprehensive safety protocols to prevent over-discharge, over-charge, and short circuits, the BOS-A prioritizes the longevity and safety of your power system.
• Robust Design: Built to withstand various environmental conditions, the BOS-A has a high IP rating and can function effectively in a range of temperatures, ensuring durability in any setting.
• Warranty Assurance: Enjoy peace of mind with a 10-year warranty, providing you with a full replacement guarantee for up to 6000 cycles of use.

Technical Specifications:

• Cell Chemistry: LiFePO₄
• Battery Dimensions: 601.5 mm x 520 mm x 135 mm
• Weight: Approx. 70 kg per rack
• Energy Efficiency: Over 90% at standard operational conditions
• Communication Port: CAN2.0, offering seamless integration with other Deye devices for a comprehensive energy management system.

Installation and Support:

The BOS-A is best suited for rack-mounted environments, with installation options available in various settings, including commercial buildings and industrial facilities. Comprehensive support is available through the Deye Cloud platform, allowing users to connect, monitor, and control their energy systems conveniently from any device.

Choose the Deye BOS-A for a smart, efficient, and reliable energy storage solution that adapts to your needs while enhancing your energy management capabilities.

MORE POWER

• Module efficiency up to 22.5 %
• Up to 4.5 % lower LCOE
• Up to 5.6 % lower system cost
• Comprehensive LID / LeTID mitigation technology, up to 50% lower degradation
• Compatible with mainstream trackers, cost-effective product for utility power plant
• Better shading tolerance

MORE RELIABLE

• Minimizes micro-crack impacts
• 40 °C lower hot spot temperature, greatly reduce module failure rate
• Heavy snow load up to 5400 Pa, enhanced wind load up to 2400 Pa
• 12 years Enhanced Product Warranty on Materials and Workmanship
• 25 years Linear Power Performance Warranty

ELECTRICAL DATA | STC

• Nominal Max. Power (Pmax): 560 W
• Opt. Operating Voltage (Vmp): 42.3 V
• Opt. Operating Current (Imp): 13.24 A
• Open Circuit Voltage (Voc): 51.4 V
• Short Circuit Current (Isc): 13.69 A
• Module Efficiency: 21.7%
• Operating Temperature: -40°C ~ +85°C
• Max. System Voltage: 1500V (IEC/UL) or 1000V (IEC/UL)
• Module Fire Performance: TYPE 1 (UL 61730 1500V) or TYPE 2 (UL 61730 1000V) or CLASS C (IEC 61730)
• Max. Series Fuse Rating: 25 A
• Application Classification: Class A
• Power Tolerance: 0 ~ + 10 W

MECHANICAL DATA

• Cell Type: Mono-crystalline
• Cell Arrangement: 144 [2 x (12 x 6)]
• Dimensions: 2278 ˣ 1134 ˣ 30 mm (89.7 ˣ 44.6 ˣ 1.18 in)
• Weight: 27.6 kg (60.8 lbs)
• Front Cover: 3.2 mm tempered glass
• Frame: Anodized aluminium alloy
• J-Box: IP68, 3 bypass diodes
• Cable: 4 mm2 (IEC), 12 AWG (UL)
• Cable Length (Including Connector): 410 mm (16.1 in) (+) / 290 mm (11.4 in) (-) (supply additional jumper cable: 2 lines / Pallet) or customized length
• Connector: T4 series or H4 UTX or MC4-EVO2
