The Galaxy A07 is the perfect entry-level device for everyday use. It offers a large display for comfortable viewing and a reliable battery that keeps you connected without breaking the bank.

DEYE BOS-W 5.1 kWh 51.2 V 100 Ah HV LiFePO₄ Battery: Advanced Energy Solution for C&I
Smart Protection: Safeguards against over-discharge, over-charge, over-current, and extreme temperatures
Safe & Reliable: Utilizes LFP technology for long-lasting performance with minimal self-discharge
Flexible Connectivity: Supports multiple battery modules in parallel; compatible with USB and remote upgrades
Wide Operating Temperature: Functions efficiently in temperatures ranging from -20°C to 55°C
High Cycle Life: Over 6000 cycles, ensuring longevity and reduced total cost of ownership
User-Friendly: Includes CAN2.0/RS485 communication ports and status indicators for easy monitoring

The Galaxy A06 LTE
covers all the essentials. It’s perfect for calls, texts, light web browsing, and social media, offering a simple and intuitive user experience with a battery that lasts.

MORE POWER

• Module efficiency up to 21.4 %
• Up to 3.5 % lower LCOE
• Up to 5.7 % lower system cost
• Comprehensive LID / LeTID mitigation technology, up to 50% lower degradation
• Compatible with mainstream trackers, cost-effective product for utility power plant
• Better shading tolerance

MORE RELIABLE

• Minimizes micro-crack impacts
• 40 °C lower hot spot temperature, greatly reduce module failure rate
• Heavy snow loads up to 5400 Pa, enhanced wind loads up to 2400 Pa
• 12 years Enhanced Product Warranty on Materials and Workmanship
• 25 years Linear Power Performance Warranty

ELECTRICAL DATA | STC

• Nominal Max. Power (Pmax): 600 W
• Opt. Operating Voltage (Vmp): 34.9 V
• Opt. Operating Current (Imp): 17.20 A
• Open Circuit Voltage (Voc): 41.3 V
• Short Circuit Current (Isc): 18.47 A
• Module Efficiency: 21.2%
• Operating Temperature: -40°C ~ +85°C
• Max. System Voltage: 1500V (IEC/UL) or 1000V (IEC/UL)
• Module Fire Performance: TYPE 1 (UL 61730 1500V) or TYPE 2 (UL 61730 1000V) or CLASS C (IEC 61730)
• Max. Series Fuse Rating: 30 A
• Application Classification: Class A
• Power Tolerance: 0 ~ + 5 W

MECHANICAL DATA

• Cell Type: Mono-crystalline
• Cell Arrangement: 120 [2 x (10 x 6)]
• Dimensions: 2172 ˣ 1303 ˣ 35 mm (85.5 ˣ 51.3 ˣ 1.38 in)
• Weight: 31.4 kg (69.2 lbs.)
• Front Cover: 3.2 mm tempered glass
• Frame: Anodized aluminum alloy
• J-Box: IP68, 3 bypass diodes
• Cable: 4 mm2 (IEC), 12 AWG (UL)
• Cable Length (Including Connector): 410 mm (16.1 in) (+) / 290 mm (11.4 in) (-) (supply additional jumper cable: 2 lines / Pallet) or customized length
• Connector: T4 series or H4 UTX or MC4-EVO2
