BOS-A is a high-performance embedded LiFePO4 battery module that offers quick installation and maintenance. With advanced safety features, intelligent BMS and eco-friendly design, it is an ideal choice for power backup and renewable energy storage. BOS-A is the ultimate solution for small-scale commercial and industrial energy storage systems (ESS). Designed for efficiency and reliability, this advanced battery system caters to a variety of power management needs while providing a sustainable energy solution.

Key Features:

• High Performance: With a capacity of 7.68 kWh and the potential for >6000 cycles, the BOS-A guarantees long-lasting energy support, ensuring that your operations run smoothly without interruptions.
• Intelligent Management: Equipped with smart cloud-based monitoring, the BOS-A enables real-time tracking of your energy consumption and battery status, optimizing performance and lowering electricity bills.
• Flexible Configuration: Capable of supporting multiple racks with up to 13 battery modules in series, this system provides adaptability to meet your growing energy demands.
• Effortless Installation: The lightweight design, at just 70 kg per module, paired with a detailed user manual, ensures a straightforward installation process.
• Safety First: Featuring an intelligent battery management system (BMS) and comprehensive safety protocols to prevent over-discharge, over-charge, and short circuits, the BOS-A prioritizes the longevity and safety of your power system.
• Robust Design: Built to withstand various environmental conditions, the BOS-A has a high IP rating and can function effectively in a range of temperatures, ensuring durability in any setting.
• Warranty Assurance: Enjoy peace of mind with a 10-year warranty, providing you with a full replacement guarantee for up to 6000 cycles of use.

Technical Specifications:

• Cell Chemistry: LiFePO₄
• Battery Dimensions: 601.5 mm x 520 mm x 135 mm
• Weight: Approx. 70 kg per rack
• Energy Efficiency: Over 90% at standard operational conditions
• Communication Port: CAN2.0, offering seamless integration with other Deye devices for a comprehensive energy management system.

Installation and Support:

The BOS-A is best suited for rack-mounted environments, with installation options available in various settings, including commercial buildings and industrial facilities. Comprehensive support is available through the Deye Cloud platform, allowing users to connect, monitor, and control their energy systems conveniently from any device.

Choose the Deye BOS-A for a smart, efficient, and reliable energy storage solution that adapts to your needs while enhancing your energy management capabilities.

The LV-HUB is a CAN communication Combiner and can be used to connect multiple master CAN communication addresses from multiple clusters that compose an LV system.

The LV-HUB-XP is not a power device LV-HUB-XP minimum startup voltage is 30 Vdc and max Input voltage is 60Vdc LV HUB-XP max current is 2A and it is equipped with built in fuse rated 5A.

The BYD Battery-Box LV Flex is a lithium iron phosphate (LFP) battery pack for use with an external inverter. The communication with the inverter is established through the Battery-Box Premium LV BMU (Battery Management Unit). Connect up to 64 LV Flex Modules in parallel on one BMU to reach individual capacities between 5 and 320 kWh. Thanks to it´s 3U design, the LV Flex can adapt to off-the-shelf racking systems. And with the possibility of stacking up to 4 units or installing them vertically, the LV Flex provides a variety of options for bespoke housing designs.

KEY FEATURES

• Perfect Battery for bespoke Projects and Integrated Systems
• Scalable from 5 kWh to 320 kWh
• Maximum Flexibility for any Application with up to 64 Modules connected in Parallel
• Compatible with Market Leading 1 and 3 Phase Inverters
• Cobalt Free Lithium Iron Phosphate (LFP) Battery: Maximum Safety, Lifespan and Power
• Capable of High-Powered Emergency-Backup and Off-Grid Function
• Self-Consumption Optimization for Residential and
  Commercial Applications

TECHNICAL PARAMETERS

• Usable Energy 5.0 kWh
• Max Cont. Output Current 70 A
• Peak Output Current 105 A, 5 s
• Dimensions (H/W/D) 132x 482 x 525 mm
• Weight 47 kg
• Nominal Voltage 51.2 V
• Operating Voltage 43.2 -57.6 V
• Operating Temperature -10 °C to +50°C
• Battery Cell Technology Lithium Iron Phosphate (cobalt-free)
• Communication CAN/RS485
• Enclosure Protection Rating IP20
• Round-trip Efficiency ≥95%
• Scalability Max. 64 in Parallel (320 kWh)
• Certification IEC62619 / CE / CEC / UN38.3 / IEC62040
• Applications ON Grid / ON Grid + Backup / OFF Grid
• Compatible Inverters Refer to BYD Battery-Box LV Flex Minimum Configuration List
• Installation method With / Without Rack

Large capacity all-in-one hybrid inverter for commercial application, supporting up to 600kW system capacity.
Features
All-in-one hybrid inverter

Battery, load, grid, and solar connection are all supported.
Programmable working mode

Peak-shaving, back-up, use the system however you want it.
Scalable design

Quadruple capacity by paralleling 4 units.
Hot back-up One inverter fails in a parallel system, the other(s) takes over seamlessly.
Touchscreen LCD

More convenient for parameter setting and maintenance.
Seamless transfer

Uninterruptable power supply guaranteed.
Dry contact output

Supports remote control of DG.
