Key Features
• Operating Voltage: 120VDC – 750VDC
• Nominal Charge / Discharge Current: 100A
• Maximum Charge / Discharge Current: 125A
• DC Input Rating: 12VDC / 4.15A
• Operating Temperature Range: -20°C to 55°C
• Ingress Protection: IP20

Key Features

• TR technology + Half Cell
  TR technology with Half-cell aims to eliminate the cell gap to increase module efficiency (mono-facial up to 21.38%)
• 9BB instead of 5BB
  9BB technology decreases the distance between bus bars and finger grid line which is benefit to power increase.
• Higher lifetime Power Yield
  2% first year degradation, 0.55% linear degradation
•  Best Warranty
  12-year product warranty, 25-year linear power warranty
• Enhanced Mechanical Load
  Certified to withstand wind load (2400 Pascal) and snow load (5400 Pascal).
•  Avoid debris, cracks and broken gate risk effectively
  9BB technology using circular ribbon that could avoid debris, cracks and broken gate risk effectively

Specification | STC

• Module Type: JKM480M-7RL3-V
• Maximum Power (Pmax): 480Wp
• Maximum Power Voltage (Vmp): 43.48V
• Maximum Power Current (Imp): 11.04A
• Open-circuit Voltage (Voc): 52.34V
• Short-circuit Current (Isc): 11.86A
• Module Efficiency STC (%): 21.38%
• Operating Temperature (℃): -40℃~+85℃
• Maximum system voltage: 1000/1500VDC (IEC)
• Maximum series fuse rating: 20A
• Power tolerance: 0~+3%
• Temperature coefficients of Pmax: -0.35%/℃
• Temperature coefficients of Voc: -0.28%/℃
• Temperature coefficients of Isc: 0.048%/℃
• Nominal operating cell temperature (NOCT): 45±2℃

Mechanical Characteristics

• Cell Type: P type Mono-crystalline
• No. of cells: 156 (2×78)
• Dimensions: 2182×1029×35mm (85.91×40.51×1.38 inch)
• Weight: 25.0kg (55.12 lbs)
• Front Glass: 3.2mm, Anti-Reflection Coating,
  High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminum Alloy
• Junction Box: IP68 Rated
• Output Cables: TUV 1×4.0mm2 (+): 250mm, (-): 150mm or Customized Length

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 12/14/16K-SG, a hybrid inverter, is suitable for residential and light commercial use, maximizing the self-consumption rate of solar energy and increasing your energy impendence.   During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 12/14/16K-SG. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It is equipped with an RS485 / CAN port for battery communication.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely makes PV plant O&M easier.

• Colorful touch LCD, IP65 protection degree
• 6 time periods for battery charging/discharging
• Max. charging/discharging current of 290A.
• Max.16pcs parallel
• DC couple and AC couple to retrofit existing solar system.
• Support storing energy from diesel generators.
• 48V low voltage battery, safe and reliable
• Unique Smart Load application and Grid peak shaving function
• 4ms fast transfer from on-grid to off-grid mode, ensuring the non-inverter type air conditioner works well.

Technical Specifications

• Solar charge controller

The MPPT VE.Can SmartSolar charger uses the latest and fastest technology to convert energy from a solar array into energy that optimally charges a battery bank.

The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulphated or otherwise damaged.

• MPPT: Ultra Fast Maximum Power Point Tracking

The MPPT VE.Can SmartSolar charger connects to a PV array of 150 or 250 Volt Voc and will automatically detect and charge your 12, 24, or 48V battery bank with current ranging from 70 to 100A depending on the model.

The charge settings are fully programmable and can even be set up for different battery chemistries, like lead-acid, lithium and others.

• Control Your Charger Remotely

The MPPT VE.Can SmartSolar charger can be remotely controlled and configured over Bluetooth via the VictronConnect App. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, and historical data.

• Daisy Chain Additional Units

The VE.Can SmartSolar charger is equipped with CAN bus ports. This allows for communication with additional VE.Can SmartSolar chargers. The additional units are simply “daisy-chained” to each other with a single RJ45 cable between the individual units.

When connected to each other, all individual VE.Can SmartSolar chargers, will synchronize their charge stages. They can also send their data, via a single cable, to a GX monitoring device.

• Remote Monitoring and Control

If the GX device is connected to the internet, the Victron Remote Management Portal (VRM) provides access to the full power of your solar charger(s).

For remote installations – even when there is no internet connection nearby – you may be able to monitor your MPPT by connecting the  GlobalLink 520.

• SmartSolar Control Display

The VE.Can SmartSolar charger is also equipped with a VE.Direct port like our other MPPT solar chargers. This port can be for single unit monitoring or for streetlight control. The remote on/off connector can be externally controlled by a third-party device like a lithium battery. An optional plug-in LCD display/control provides live-data, set-up and management, straight from the face of the device.
