Unmatched Energy Capacity for Industrial Applications

Power your operations with the WECO 16K0 HV Industrial High Voltage Rack Module battery, engineered to meet the demands of modern industrial setups. With an impressive capacity of 16.0 kWh (314VAh), this robust energy solution guarantees reliable performance and extended uptime for your high-energy systems. Its nominal voltage of 51.2Vdc ensures seamless integration into high-voltage applications, delivering efficiency without compromising safety or durability.

Durable and Versatile Design

Crafted for longevity and adaptability, the WECO 16K0 HV battery rack module is built to handle the toughest environments. Whether you’re scaling energy storage for manufacturing plants, renewable energy systems, or high-performance machinery, this module delivers unwavering support. Its modular rack design simplifies installation, maintenance, and scalability, ensuring your workflow remains uninterrupted. The high-quality components provide enhanced reliability, contributing to reduced operational downtime and consistent power supply.

Why Choose the WECO 16K0 HV Battery?

This advanced battery module isn’t just about energy storage—it’s about optimizing your industrial efficiency. The high voltage capability allows for efficient energy transfer and integration with modern equipment, giving you more power per cycle. Its cutting-edge engineering also focuses on sustainability, reducing energy waste and minimizing environmental impact. The WECO 16K0 HV battery is ideal for industries and systems that demand peak performance, scalability, and reliability.

Key Features

• TR technology + Half Cell
  TR technology with Half-cell aims to eliminate the cell gap to increase module efficiency (mono-facial up to 21.38%)
• 9BB instead of 5BB
  9BB technology decreases the distance between bus bars and finger grid line which is benefit to power increase.
• Higher lifetime Power Yield
  2% first year degradation, 0.55% linear degradation
•  Best Warranty
  12-year product warranty, 25-year linear power warranty
• Enhanced Mechanical Load
  Certified to withstand wind load (2400 Pascal) and snow load (5400 Pascal).
•  Avoid debris, cracks and broken gate risk effectively
  9BB technology using circular ribbon that could avoid debris, cracks and broken gate risk effectively

Specification | STC

• Module Type: JKM480M-7RL3-V
• Maximum Power (Pmax): 480Wp
• Maximum Power Voltage (Vmp): 43.48V
• Maximum Power Current (Imp): 11.04A
• Open-circuit Voltage (Voc): 52.34V
• Short-circuit Current (Isc): 11.86A
• Module Efficiency STC (%): 21.38%
• Operating Temperature (℃): -40℃~+85℃
• Maximum system voltage: 1000/1500VDC (IEC)
• Maximum series fuse rating: 20A
• Power tolerance: 0~+3%
• Temperature coefficients of Pmax: -0.35%/℃
• Temperature coefficients of Voc: -0.28%/℃
• Temperature coefficients of Isc: 0.048%/℃
• Nominal operating cell temperature (NOCT): 45±2℃

Mechanical Characteristics

• Cell Type: P type Mono-crystalline
• No. of cells: 156 (2×78)
• Dimensions: 2182×1029×35mm (85.91×40.51×1.38 inch)
• Weight: 25.0kg (55.12 lbs)
• Front Glass: 3.2mm, Anti-Reflection Coating,
  High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminum Alloy
• Junction Box: IP68 Rated
• Output Cables: TUV 1×4.0mm2 (+): 250mm, (-): 150mm or Customized Length

• Panels and system monitoring

The Color Control GX is the communication center of your installation. It offers at-a-glance live information and lets you control all products connected to it. Full system control is gained – almost anywhere in the world – by accessing your Color Control GX using our free-to-use Victron Remote Management Portal (VRM).

• Intuitive system overview – all you need to know

With a single touch, Color Control GX provides an instant overview of your system: battery state of charge; present power consumption; power harvest from PV; power provision from mains/generator.

• The full power of Victron Remote Management

Victron Remote Management (VRM) provides you with full access to the very extensive controls and settings of all system components which are connected to either your CCGX or Venus GX. It allows the remote user and installer to log in from anywhere, at any time. This powerful application also provides for hassle-free diagnostic checks and analysis of archived information.

• Automatic Generator start/stop

The Color Control GX can be programmed to auto-start your generator – triggered by low-voltage; high-demand; or battery state of charge. It can be further tailored to delay ignition until the end of ‘quiet’ periods – avoiding accidental nuisance at dead of night.

• Remote Console – control everything from anywhere…

A Remote Console feature is available. It’s like carrying the front face of your CCGX control panel around on your phone, or other device.

• Energy Storage Systems – 24 hour Monitoring

The Color Control GX manages Energy Storage Systems. It keeps back-up batteries at 100% ; kicks-in during power-cuts; and diverts excess (solar) power to self-consumption – saving you money. For examples and more detailed information see the ESS (Energy Storage System) manual.

• Remotely monitor your boat or motorhome electrics

Planning a trip? Remote monitoring of your Color Control GX allows you to make sure your boat or motor home are ready to go. Color Control GX also allows you to talk to connected equipment from other manufacturers.

African Energy modules are made by some of the world’s most sophisticated module manufacturers and are designed for Africa’s off-grid solar charging and water pumping needs. The modules include efficient crystalline cells set in a solid aluminum frame and feature TÜV and IEC certification. With a 30-year warranty, these modules can provide power for several generations – and the quality is assured by African Energy’s decade of experience in the solar industry.

Electrical Characteristics:

• Maximum Power at STC (Pmax) 620 W
• Optimum Operating Voltage (Vmp) 40.93 V
• Optimum Operating Current (Imp) 12.90 A
• Open Circuit Voltage (Voc) 48.40 V
• Short Circuit Current (Isc) 13.70 A
• Module Efficiency 22.95%
• Operating Module Temperature -40 °C to +85 °C
• Maximum System Voltage 1000/1500 V DC (IEC)
• Maximum Series Fuse Rating 20 A
• Power Tolerance 0/+5 %
• 30-year warranty

Mechanical Specifications:

• Solar Cells Monocrystalline 144 (72*2) pcs
• No. of Cells 144 (72*2)
• Dimensions 2278x1134x30mm
• Weight 28.3kg
• Front Glass High transparency solar glass 3.2mm
• Frame Black/Silver Anodized aluminum alloy
• Junction Box IP68 rated
• Output Cables 4.0 mm2, portrait: 300mm/300mm
• Connector MC4 Compatible
• Wind/Snow Load 2400pa/5400pa
