Specification | STC

• Module Type: JKM555N-72HL4-V
• Maximum Power (Pmax): 555Wp
• Maximum Power Voltage (Vmp): 41.64V
• Maximum Power Current (Imp): 13.33A
• Open-circuit Voltage (Voc): 50.34V
• Short-circuit Current (Isc): 14.07A
• Module Efficiency STC (%): 21.48%
• Operating Temperature (℃): -40℃~+85℃
• Maximum system voltage: 1000/1500VDC (IEC)
• Maximum series fuse rating: 25A
• Power tolerance: 0~+3%
• Temperature coefficients of Pmax: -0.35%/℃
• Temperature coefficients of Voc: -0.28%/℃
• Temperature coefficients of Isc: 0.048%/℃
• Nominal operating cell temperature (NOCT): 45±2℃

Mechanical Characteristics

• Cell Type: N type Mono-crystalline
• No. of cells: 144 (6×24)
• Dimensions: 2278×1134×35mm (89.69×44.65×1.38 inch)
• Weight: 28.9 kg (61.73 lbs)
• Front Glass: 3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminium Alloy
• Junction Box: IP68 Rated
• Output Cables: TUV 1×4.0mm2 (+): 400mm , (-): 200mm or Customized Length

The WeCo High-Voltage Connection Module is an essential component for seamless high-voltage serial connections of the WeCo Battery system. Designed for efficiency and reliability, this module ensures a secure and robust link between batteries, optimizing energy storage performance.

The EcoBoost MPPT solar charge controller brings Morningstar’s proprietary TrakStar Technology to our new line of Essentials

controllers and accessories. The EcoBoost controllers automatically detect 12 or 24 V system configuration. They are highly efficient and accurate controllers designed to ensure that batteries attain a complete state of charge.

They are also sophisticated load controllers. Using this feature to manage DC power consumption protects the batteries from over discharge and helps ensure long-term system reliability. Small DC loads can be powered directly from the EcoBoost by way of two USB
charging ports.

Morningstar EcoBoost controllers act as the central brain of PV powered DC electrical systems up to 1,120 watts and offer outstanding value, performance, and dependability.

KEY FEATURES AND BENEFITS

• Rugged, Maintenance-free Design

Conformally coated circuit board and corrosion resistant terminals.

• Maximizes Energy Harvest

Using TrakStar MPPT technology to determine and adjust to the true maximum power point as solar insolation changes throughout the day.

• High Efficiency

At low, medium, and high power levels.

• Optional Meter

Provides access to system operational information, including current and historical performance data. All EcoBoost “M” controllers include the meter.

Power your commercial solar installation with confidence using the Fronius Verto 33.3, a robust and highly efficient string inverter engineered for optimal performance and maximum energy yield. Building on Fronius’s legacy of innovation, the Verto 33.3 is designed to meet the demanding requirements of medium to large-scale commercial and industrial photovoltaic systems.

Key Features & Benefits:

* Exceptional 33.3 kW Power Output: Delivers substantial power for significant energy generation, making it ideal for a wide range of commercial applications.
* High Efficiency for Maximized Yield: Engineered to convert more solar DC power into usable AC electricity, ensuring you get the most out of your solar array and achieve faster ROI.
* Robust & Reliable Design: Built with Fronius’s renowned quality and durability, the Verto 33.3 is designed for long-term, reliable operation in various environmental conditions.
* Flexible System Design: Features multiple Maximum Power Point Trackers (MPPTs) for flexible system design, optimizing energy harvest even with partial shading or varying string orientations.
* Advanced Grid Management Functions: Equipped with advanced grid support functionalities, ensuring seamless integration with the grid and compliance with local regulations.
* Integrated Data Communication: Comes with integrated data communication for easy monitoring of system performance via the Fronius Solar.web platform, providing real-time insights and remote access.
* Easy Installation & Servicing: Designed with installer convenience in mind, featuring a user-friendly interface and accessible components for straightforward setup and maintenance.
* Suitable for Diverse Commercial Applications: Perfect for rooftops of businesses, industrial facilities, agricultural buildings, and other large-scale commercial solar projects.
* Fronius Quality and Support: Backed by Fronius’s established reputation for innovation, quality, and comprehensive customer support.

Technical Specifications:

* AC Nominal Power: 33.3 kW
* Number of MPP Trackers: 4
* Max. DC Voltage: 1000 V
* Dimensions (H x W x D): 730 x 540 x 278
* Weight: 35.20 kg
* Cooling: Active cooling technology
* Protection Class: IP66

Invest in the Fronius Verto 33.3 inverter for a powerful, efficient, and dependable solution that will drive the success of your commercial solar investment.
