Suntree 1000V DC Solar PV Combiner Box – 2 Strings Input, 1 String Output, Ideal for Off-Grid Solar Systems in Africa.

Looking to set up an off-grid solar power system in Africa? The Suntree 1000V DC Solar PV Combiner Box is your perfect solution. Designed for efficient solar energy management, it offers 2 strings input and 1 string output, making it ideal for renewable energy solutions across Africa, from Kenya to South Africa.

This combiner box features high reliability with built-in DC fuses, surge protection devices, and a DC circuit breaker or load isolation switch, ensuring a safe and stable solar power system. The durable PVC engineering material offers IP65 protection, making it waterproof, dustproof, and UV-resistant—perfect for Africa’s diverse climate.

Tested for fire retardance, temperature stability, and anti-impact capabilities, the Suntree combiner box meets the CGC/GF 037:2014 standards. It’s suitable for single crystal silicon, polycrystalline silicon, and thin-film solar modules, ensuring flexible configuration for various solar installations.

Whether you’re looking for solar battery storage in Africa, want to know the cost of solar panels, or are interested in setting up solar power for your home, the Suntree combiner box makes solar power installation seamless. Experience the benefits of solar energy in Africa with this reliable, high-quality solution.

For more information on the price of a solar power system or to buy a solar power system in Africa, reach out today!

Specification | STC

• Module Type: JKM575N-72HL4-V
• Maximum Power (Pmax): 575Wp
• Maximum Power Voltage (Vmp): 42.22V
• Maximum Power Current (Imp): 13.62A
• Open-circuit Voltage (Voc): 50.88V
• Short-circuit Current (Isc): 14.39A
• Module Efficiency STC (%): 22.26%
• Operating Temperature (℃): -40℃~+85℃
• Maximum system voltage: 1000/1500VDC (IEC)
• Maximum series fuse rating: 25A
• Power tolerance: 0~+3%
• Temperature coefficients of Pmax: -0.35%/℃
• Temperature coefficients of Voc: -0.28%/℃
• Temperature coefficients of Isc: 0.048%/℃
• Nominal operating cell temperature (NOCT): 45±2℃

Mechanical Characteristics

• Cell Type: N type Mono-crystalline
• No. of cells: 144 (6×24)
• Dimensions: 2278×1134×35mm (89.69×44.65×1.38 inch)
• Weight: 28.9 kg (61.73 lbs)
• Front Glass: 3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminium Alloy
• Junction Box: IP68 Rated
• Output Cables: TUV 1×4.0mm2 (+): 400mm , (-): 200mm or Customized Length

• • Multifunctional

  Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally, it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple systems integration features such as three or split-phase operation and parallel operation.

  • Two AC Inputs & two AC Outputs

  The Quattro can be connected to two independent AC sources, for example, shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is life only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.

  • Unique PowerAssist feature

  The Quattro will prevent the overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shoreside supply with power taken from the battery.

  • Virtually unlimited power thanks to parallel operation

  Up to 6 Quattros can operate in parallel to achieve higher power output. Three-phase or split-phase operation is also possible. Please check our datasheets to see which models have parallel, three-phase, and split-phase capabilities.

  • Remote Monitoring and Control

  Monitor and control your Quattro and system or systems locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Quattro to setting a Geofence for-hire vehicles and more…

Unmatched Performance for Energy Optimization

Experience peak efficiency in energy management with the DEYE 16 kW Three Phase 3 MPPT Hybrid Inverter – SUN-16K-SG05LP3E-EU. Specifically designed to empower solar energy systems, this advanced inverter offers groundbreaking technology that bridges high output with exceptional reliability. Whether you’re powering a residential property or a larger commercial setup, this is the ideal solution for ensuring optimal energy utilization.

Advanced Three MPPT Technology

At the core of this hybrid inverter lies its state-of-the-art MPPT (Maximum Power Point Tracking) technology. With three MPPT channels, the DEYE 16 kW inverter guarantees precise tracking and harvesting of solar energy even in challenging weather conditions. By maximizing the energy captured from your solar panels, you can significantly reduce energy waste and enhance overall system performance over time.

Durable and Versatile with Three-Phase Power

Built for flexibility and durability, the DEYE 16 kW Hybrid Inverter supports three-phase power output, catering to high-demand energy systems with seamless integration. This feature ensures compatibility with both residential and industrial applications, delivering consistent, uninterrupted power supply regardless of your operational scale. Its robust design ensures long-lasting performance and protection against environmental stressors.

Why Choose DEYE’s Hybrid Solution?

The SUN-16K-SG05LP3E-EU is more than an inverter – it’s a strategic energy investment for those seeking reliability, efficiency, and adaptability. With hybrid capabilities, it effortlessly connects solar, grid, and battery systems, providing you with greater autonomy and control over your power consumption. Additionally, its intuitive system design makes monitoring your energy output a hassle-free experience.

Transform your energy management strategy with the DEYE 16 kW Three Phase 3 MPPT Hybrid Inverter. Engineered for superior performance and longevity, it’s the perfect partner for harnessing sustainable energy. Don’t miss out on this cutting-edge solution tailored to meet your energy needs with utmost efficiency.
