The connection between BMU and Battery-Box should be the Straight-Through Wired Cable (CAT 5 shield or above, not longer than 10m).

Detailed connection instructions with inverters could be read in the Battery-Box LVS/LVL Quick Start Guide.

Properties:

•  Protection rating: IP55
•  Communication: Ethernet / CAN / RS485
•  Input voltage: 40-60V (Supply by Battery-Box through network cable)
•  Input current: 200mA
•  Dimensions (L/W/H): 222x154x5

The Huawei Inverter SUN2000-60KTL-MO is a smart string inverter used in commercial installations. The inverter can reach a high efficiency (98,9% max efficiency, 98,7% European efficiency). The device is very safe and reliable because of different applied solutions.

Smart string inverter

Up to 12 strings can be connected to this inverter. Which can be, individually, per string, monitored. There are 6 MPPTs to optimize connected solar modules. Shading and differences in the way each module of the setup is positioned have less of an impact on performance.

Safety and reliability

A Huawei Inverter SUN2000-60KTL MO (66kW) – 400V has an IP65 rating, meaning the device is protected from water and corrosion entering the device. The risk of fire because of electric arcs is minimized since there is no need for DC Combiner Boxes or fuses. Instead of a fuse, there is an RCMU, or a Residual Current Monitoring Unit. These monitor stray currents and in case of an error or fault will send a signal to terminate the current. Also present is a Type 2 SPD for both DC and AC.

Choose certainty, extend your warranty.

Do you want absolute certainty your inverter will remain functional? Extend the warranty for your Huawei inverter by 10, 15 or 20 years.

Specification | STC

• Module Type: JKM575N-72HL4-V
• Maximum Power (Pmax): 575Wp
• Maximum Power Voltage (Vmp): 42.22V
• Maximum Power Current (Imp): 13.62A
• Open-circuit Voltage (Voc): 50.88V
• Short-circuit Current (Isc): 14.39A
• Module Efficiency STC (%): 22.26%
• Operating Temperature (℃): -40℃~+85℃
• Maximum system voltage: 1000/1500VDC (IEC)
• Maximum series fuse rating: 25A
• Power tolerance: 0~+3%
• Temperature coefficients of Pmax: -0.35%/℃
• Temperature coefficients of Voc: -0.28%/℃
• Temperature coefficients of Isc: 0.048%/℃
• Nominal operating cell temperature (NOCT): 45±2℃

Mechanical Characteristics

• Cell Type: N type Mono-crystalline
• No. of cells: 144 (6×24)
• Dimensions: 2278×1134×35mm (89.69×44.65×1.38 inch)
• Weight: 28.9 kg (61.73 lbs)
• Front Glass: 3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminium Alloy
• Junction Box: IP68 Rated
• Output Cables: TUV 1×4.0mm2 (+): 400mm , (-): 200mm or Customized Length

S6-EH3P15K02-NV-YD-L series three-phase hybrid inverter is suitable for large residential PV energy storage systems with low battery voltage (48V). The products are compatible with high-power PV panels, and suitable for a variety of brands’ lithium and lead-acid batteries. In addition, the product has a wealth of features, including compatible generators, UPS level switching, grid-tied PV system coupling networking, supporting three-phase unbalanced load and half-wave load, etc. Helps households easily achieve zero carbon energy needs.

Three-Phase Low Voltage Energy Storage Inverter

Leading Features

• Built-in control for SG-ready heat pumps
• 7-inch LCD screen for an intuitive user experience
• Bluetooth app support for quick and easy setup
• Compatible with mainstream lithium and lead-acid batteries
• 160% PV input capacity to maximize solar energy utilization
• Easily expand system capacity using parallel connections and AC coupling
• AI intelligently manages charging and discharging based on TOU (Time-of-Use) tariffs
• Seamless integration with VPP and EMS platforms for enhanced energy optimization
• Supports three-phase unbalanced output, allowing up to 50% of rated inverter power per phase
