Higher yields / Safe & Reliable / Smart / User-friendly

The series, SUN-5/6K-SG01LP1-US SUN-7.6/8K-SG01LP1-US/EU, is a single-phase low voltage (48V) hybrid inverter that enables enhanced energy independence and maximizes self-consumption through export limit feature and “time of use” function. With the frequency droop control algorithm, this series product supports single-phase and three-phase parallel applications and the Max. parallel units are up to 16 PCs.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely makes PV plant O&M easier.

• Colorful touch LCD, IP65 protection degree
• 6 time periods for battery charging/discharging
• Max. charging/discharging current of 190A.
• Max.16pcs parallel
• DC coupled and AC coupled to retrofit existing solar system.
• Support storing energy from diesel generators.
• Max. battery charge efficiency of 95.4%
• Unique Smart Load application and Grid peak shaving function
• 4ms fast transfer from on-grid to off-grid mode, ensuing the traditional fixed frequency air conditioner works well
• Certified by UL, CE, IEC, VDE, NRS, VFR, AS4777.2, CEI and INMETRO, etc.

Technical Specifications

MORE POWER

• Module power up to 670 W
• Module efficiency up to 21.6 %
• Up to 3.5 % lower LCOE
• Up to 5.7 % lower system cost
• Comprehensive LID / LeTID mitigation technology, up to 50% lower degradation
• Better shading tolerance

MORE RELIABLE

• 40 °C lower hot spot temperature, greatly reduce module failure rate
• Minimizes micro-crack impacts
• Heavy snow load up to 5400 Pa, wind load up to 2400 Pa*

ELECTRICAL DATA | STC

• Nominal Max. Power (Pmax): 665 W
• Opt. Operating Voltage (Vmp): 38.5 V
• Opt. Operating Current (Imp): 17.28 A
• Open Circuit Voltage (Voc): 45.6 V
• Short Circuit Current (Isc): 18.51 A
• Module Efficiency: 21.4%
• Operating Temperature: -40°C ~ +85°C
• Max. System Voltage: 1500V (IEC/UL) or 1000V (IEC/UL)
• Module Fire Performance: TYPE 1 (UL 61730 1500V) or TYPE 2 (UL 61730 1000V) or CLASS C (IEC 61730)
• Max. Series Fuse Rating: 35 A
• Application Classification: Class A
• Power Tolerance: 0 ~ + 10 W

MECHANICAL DATA

• Cell Type: Mono-crystalline
• Cell Arrangement: 132 [2 x (11 x 6) ]
• Dimensions: 2384 ˣ 1303 ˣ 35 mm (93.9 ˣ 51.3 ˣ 1.38 in)
• Weight: 37.9 kg (83.6 lbs)
• Front Cover: 3.2 mm tempered glass
• Frame: Anodized aluminium alloy, crossbar enhanced
• J-Box: IP68, 3 bypass diodes
• Cable: 4 mm2 (IEC), 10 AWG (UL)
• Cable Length (Including Connector): 460 mm (18.1 in) (+) / 340 mm (13.4 in) (-) (supply additional jumper cable: 2 lines / Pallet) or customized length*
• Connector: T4 series or MC4-EVO2
• Per Pallet: 31 pieces
• Per Container (40′ HQ): 527 pieces

ATESS Automatic Transfer Switch is an accessory of HPS, when both the grid and the DG need to access HPS, the Automatic Transfer Switch will be used to switch between the grid and DG automatically.

Features:

• HPS compatible
• Flexible management
• Support remote control of DG.
• Transfer automatically between grid and DG.
