ATESS Batt-Master Cabinet – 9R -280R

Higher yields / Safe & Reliable / Smart / User-friendly

The series, SUN-5/6K-SG01LP1-US SUN-7.6/8K-SG01LP1-US/EU, is a single-phase low voltage (48V) hybrid inverter that enables enhanced energy independence and maximizes self-consumption through export limit feature and “time of use” function. With the frequency droop control algorithm, this series product supports single-phase and three-phase parallel applications and the Max. parallel units are up to 16 PCs.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely makes PV plant O&M easier.

• Colorful touch LCD, IP65 protection degree
• 6 time periods for battery charging/discharging
• Max. charging/discharging current of 190A.
• Max.16pcs parallel
• DC coupled and AC coupled to retrofit existing solar system.
• Support storing energy from diesel generators.
• Max. battery charge efficiency of 95.4%
• Unique Smart Load application and Grid peak shaving function
• 4ms fast transfer from on-grid to off-grid mode, ensuing the traditional fixed frequency air conditioner works well
• Certified by UL, CE, IEC, VDE, NRS, VFR, AS4777.2, CEI and INMETRO, etc.

Technical Specifications

The BYD B-Box Premium LVL has powerful on-grid, backup and off-grid functions for private and commercial applications.

The new battery storage also has protection rating IP20. This means that the BYD B-Box Premium LVL 15.4 can only be used indoors.

Flexible and Scalable

In total, up to 64 B-Box Premium LVL 15.4 can be connected in parallel to achieve a total capacity of 983.04 kWh.

The BYD Battery-Box Premium LVL 15.4 is compatible with the market leading 1- and 3-phase inverters from GoodWe, Victron and SMA (Sunny Island).

Advantages of the BYD B-Box Premium

• All models of the Battery-Box Premium series comply with the VDE 2510 safety standard and have additional safety functions for installation.
• The systems support parallel connections without the need for additional communication devices.
• They are more flexible and scalable and cover a wider range of applications.
• The new cobalt-free premium generation also features a higher energy density and a more compact format, thus requiring less floor space.
• The higher capacity per module reduces the number of components. In combination with the improved design and a new locking mechanism, this should make installation easier and reduce installation time.
• Lithium Iron Phosphate Battery (LFP): Maximum safety, lifetime and performance
• In addition to a new LED status display, there is also a new interface and the option of remote control.

• • Multifunctional

  Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally, it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple systems integration features such as three or split-phase operation and parallel operation.

  • Two AC Inputs & two AC Outputs

  The Quattro can be connected to two independent AC sources, for example, shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is life only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.

  • Unique PowerAssist feature

  The Quattro will prevent the overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shoreside supply with power taken from the battery.

  • Virtually unlimited power thanks to parallel operation

  Up to 6 Quattros can operate in parallel to achieve higher power output. Three-phase or split-phase operation is also possible. Please check our datasheets to see which models have parallel, three-phase, and split-phase capabilities.

  • Remote Monitoring and Control

  Monitor and control your Quattro and system or systems locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Quattro to setting a Geofence for-hire vehicles and more…
