Unmatched Energy Capacity for Industrial Applications

Power your operations with the WECO 16K0 HV Industrial High Voltage Rack Module battery, engineered to meet the demands of modern industrial setups. With an impressive capacity of 16.0 kWh (314VAh), this robust energy solution guarantees reliable performance and extended uptime for your high-energy systems. Its nominal voltage of 51.2Vdc ensures seamless integration into high-voltage applications, delivering efficiency without compromising safety or durability.

Durable and Versatile Design

Crafted for longevity and adaptability, the WECO 16K0 HV battery rack module is built to handle the toughest environments. Whether you’re scaling energy storage for manufacturing plants, renewable energy systems, or high-performance machinery, this module delivers unwavering support. Its modular rack design simplifies installation, maintenance, and scalability, ensuring your workflow remains uninterrupted. The high-quality components provide enhanced reliability, contributing to reduced operational downtime and consistent power supply.

Why Choose the WECO 16K0 HV Battery?

This advanced battery module isn’t just about energy storage—it’s about optimizing your industrial efficiency. The high voltage capability allows for efficient energy transfer and integration with modern equipment, giving you more power per cycle. Its cutting-edge engineering also focuses on sustainability, reducing energy waste and minimizing environmental impact. The WECO 16K0 HV battery is ideal for industries and systems that demand peak performance, scalability, and reliability.

Key Features

• N-type TechnologyN-type modules with Tunnel Oxide Passivating Contacts (TOPcon) technology offer lower LID/LeTID degradation and better low light
  performance.
• HOT 3.0 TechnologyN-type modules with Jinko Solar’s HOT 3.0 technology offer better reliability and efficiency.
• Durability Against Extreme EnvironmentHigh salt mist and ammonia resistance.
• Mechanical Load EnhancedCertified to withstand:
  5400 Pa front side max static test load
  2400 Pa rear side max static test load.
• SMBB TechnologyBetter light trapping and current collection to improve module power output and reliability.
• Anti-PID GuaranteeMinimizes the chance of degradation caused by PID phenomena through optimization of cell production technology and material
  control.

Specification | STC

• Module Type: JKM615N-66HL4M-V
• Maximum Power (Pmax): 615Wp
• Maximum Power Voltage (Vmp): 40.73V
• Maximum Power Current (Imp): 15.10A
• Open-circuit Voltage (Voc): 48.79V
• Short-circuit Current (Isc): 16.08A
• Module Efficiency STC (%): 22.77%
• Temperature Coefficients of Pmax: -0.29 %/°C
• Temperature Coefficients of Voc: -0.25 %/°C
• Temperature Coefficients of Isc: 0.045 %/°C
• Power tolerance: 0~+3%
• Operating Temperature: -40 °C ~ +70°C
• Maximum System Voltage: 1000/1500 VDC (IEC)
• Maximum Series Fuse Rating: 30 A

Mechanical Characteristics

• Cell Type: N -type Mono-crystalline
• No. of cells: 132 (66×2)
• Dimensions: 2382×1134×35 mm
• Weight: 28.2 kg
• Front Glass: 3.2mm, Anti-reflection Coating, High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminum Alloy
• Junction Box: IP68 Rated
• Protection Class: Class II
• IEC Fire Type: Class C
• Connector Type: K03M/MC4/Others
• Output Cables: 4.0 mm2 (+): 400 mm, (-): 200 mm or Customized Length

MORE POWER

• Module efficiency up to 21.4 %
• Up to 3.5 % lower LCOE
• Up to 5.7 % lower system cost
• Comprehensive LID / LeTID mitigation technology, up to 50% lower degradation
• Compatible with mainstream trackers, cost-effective product for utility power plant
• Better shading tolerance

MORE RELIABLE

• Minimizes micro-crack impacts
• 40 °C lower hot spot temperature, greatly reduce module failure rate
• Heavy snow loads up to 5400 Pa, enhanced wind loads up to 2400 Pa
• 12 years Enhanced Product Warranty on Materials and Workmanship
• 25 years Linear Power Performance Warranty

ELECTRICAL DATA | STC

• Nominal Max. Power (Pmax): 600 W
• Opt. Operating Voltage (Vmp): 34.9 V
• Opt. Operating Current (Imp): 17.20 A
• Open Circuit Voltage (Voc): 41.3 V
• Short Circuit Current (Isc): 18.47 A
• Module Efficiency: 21.2%
• Operating Temperature: -40°C ~ +85°C
• Max. System Voltage: 1500V (IEC/UL) or 1000V (IEC/UL)
• Module Fire Performance: TYPE 1 (UL 61730 1500V) or TYPE 2 (UL 61730 1000V) or CLASS C (IEC 61730)
• Max. Series Fuse Rating: 30 A
• Application Classification: Class A
• Power Tolerance: 0 ~ + 5 W

MECHANICAL DATA

• Cell Type: Mono-crystalline
• Cell Arrangement: 120 [2 x (10 x 6)]
• Dimensions: 2172 ˣ 1303 ˣ 35 mm (85.5 ˣ 51.3 ˣ 1.38 in)
• Weight: 31.4 kg (69.2 lbs.)
• Front Cover: 3.2 mm tempered glass
• Frame: Anodized aluminum alloy
• J-Box: IP68, 3 bypass diodes
• Cable: 4 mm2 (IEC), 12 AWG (UL)
• Cable Length (Including Connector): 410 mm (16.1 in) (+) / 290 mm (11.4 in) (-) (supply additional jumper cable: 2 lines / Pallet) or customized length
• Connector: T4 series or H4 UTX or MC4-EVO2

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 12/14/16K-SG, a hybrid inverter, is suitable for residential and light commercial use, maximizing the self-consumption rate of solar energy and increasing your energy impendence.   During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 12/14/16K-SG. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It is equipped with an RS485 / CAN port for battery communication.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely makes PV plant O&M easier.

• Colorful touch LCD, IP65 protection degree
• 6 time periods for battery charging/discharging
• Max. charging/discharging current of 290A.
• Max.16pcs parallel
• DC couple and AC couple to retrofit existing solar system.
• Support storing energy from diesel generators.
• 48V low voltage battery, safe and reliable
• Unique Smart Load application and Grid peak shaving function
• 4ms fast transfer from on-grid to off-grid mode, ensuring the non-inverter type air conditioner works well.

Technical Specifications
