OutBack Power’s new MATE3s display and controller offer advanced features for monitoring and controlling your OutBack Power system.  Remotely manage and monitor multiple inverter/chargers, and DC monitoring devices with this well-designed controller.  The MATE3s intuitive user interface and integrated system configuration wizard make programming and setup simple.

The OutBack MATE3s controller’s unique multi-level password feature allows you to secure critical system settings from unintended changes while still allowing open access to necessary functions.  A built-in clock and calendar function allows for detailed timer-based programming of inverter and charger operation.  Settings are stored in permanent memory to preserve settings in the event of system shutdown.

The MATE3s features full remote system monitoring via an easy-to-use web interface.  An SD memory card slot allows you to increase data logging capacity as well as upgrade units in the field.  Web connectivity is provided with an included CAT 5 network cable with an RJ45 modular jack.

Large capacity all-in-one hybrid inverter for commercial application, supporting up to 600kW system capacity.
Features
All-in-one hybrid inverter

Battery, load, grid, and solar connection are all supported.
Programmable working mode

Peak-shaving, back-up, use the system however you want it.
Scalable design

Quadruple capacity by paralleling 4 units.
Hot back-up One inverter fails in a parallel system, the other(s) takes over seamlessly.
Touchscreen LCD

More convenient for parameter setting and maintenance.
Seamless transfer

Uninterruptable power supply guaranteed.
Dry contact output

Supports remote control of DG.

The HV-HUB is a CAN communication Combiner and can be used to connect multiple master CAN communication addresses from multiple clusters that compose an LV system.

The HV-HUB-XP is not a power device HV-HUB-XP minimum startup voltage is 30 Vdc and max Input voltage is 60Vdc HV HUB-XP max current is 2A and it is equipped with built in fuse rated 5A.

Higher yields / Safe & Reliable / Smart / User-friendly

SUN 12/14/16K-SG, a hybrid inverter, is suitable for residential and light commercial use, maximizing the self-consumption rate of solar energy and increasing your energy impendence.   During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 12/14/16K-SG. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It is equipped with an RS485 / CAN port for battery communication.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely makes PV plant O&M easier.

• Colorful touch LCD, IP65 protection degree
• 6 time periods for battery charging/discharging
• Max. charging/discharging current of 290A.
• Max.16pcs parallel
• DC couple and AC couple to retrofit existing solar system.
• Support storing energy from diesel generators.
• 48V low voltage battery, safe and reliable
• Unique Smart Load application and Grid peak shaving function
• 4ms fast transfer from on-grid to off-grid mode, ensuring the non-inverter type air conditioner works well.

Technical Specifications
