ATESS PV combiner box is an accessory for multiple PV strings connection, it is with smart controller inbuilt for monitoring, along with comprehensive protections including fuse and SPD.

Features:

• Lightning protection
• Optional string monitoring function
• RS485 communication interface
• Input fuse for over current protection
• IP65 environment compatibility
• Flexible design, 8,16 inputs optional

The Huawei SUN2000-50KTL-M3 combines efficiency with ease of use. As an indispensable component of the PV system, the inverter is designed to convert direct current from the solar cells into alternating current. In this form, it can be used or fed into the grid.

Features:

• 3-phase inverter with 55,000VA power
• 4 independent MPP trackers
• Efficiency up to 98.5%
• Compatible with module optimizer MERC-1100W-P, MERC-1300W-P
• Communication via 2G, 3G, 4G, Ethernet (with optional dongle), RS485, AC & DC-MBUS
• Free system monitoring with FusionSolar
• RS485 for Smart Power Sensor & SmartLogger
• Integrated AC and DC overvoltage protection TYPE II
• Integrated PID recovery
• intelligent air cooling
• Protection class IP66

OutBack Power’s new MATE3s display and controller offer advanced features for monitoring and controlling your OutBack Power system.  Remotely manage and monitor multiple inverter/chargers, and DC monitoring devices with this well-designed controller.  The MATE3s intuitive user interface and integrated system configuration wizard make programming and setup simple.

The OutBack MATE3s controller’s unique multi-level password feature allows you to secure critical system settings from unintended changes while still allowing open access to necessary functions.  A built-in clock and calendar function allows for detailed timer-based programming of inverter and charger operation.  Settings are stored in permanent memory to preserve settings in the event of system shutdown.

The MATE3s features full remote system monitoring via an easy-to-use web interface.  An SD memory card slot allows you to increase data logging capacity as well as upgrade units in the field.  Web connectivity is provided with an included CAT 5 network cable with an RJ45 modular jack.

UF5000 is the latest Pylontech 48V LFP battery with bigger capacity at 5.12kWh modular and stronger functions for high current strike endurance, dual active protection, remote upgrade feature, widely internal compatibility up to 20 modules per single string.

Advantage

• Flexible for Mixed Usage
• Free to Scale Up
• 19 inches Rack Compatible
• High Power Efficiency

Technical Specifications

• Nominal Voltage (VDC): 51.2
• Nominal Capacity (kWh): 5.12
• Usable Capacity (kWh): 4.864
• Dimension (W*D*H mm): 442*420*161
• Weight (kg): 42
• Depth of Discharge: 95%
• Charge/Discharge (A) (Normal): 100
• Charge/Discharge (A) (Max): 100
• Charge/Discharge (A) (Peak): 121-200 @15s
• Communication Port: RS485/CAN
• Single String Quantity (pcs): 20
• Working Temperature/ (℃) Charge: -10~55
• Working Temperature/ (℃) Discharge: -10~55
• Storage Temperature/ (℃): -20~60
• Short current/duration time (A): <2000/1ms
• IP rating: IP20
• Humidity (RH): 5%-95% No Condensation
• Altitude (m): <4000
• Design life (@25℃): 15 years
• Cycle Life (@25℃): >6000
• Certification: IEC62619/UN38.3/RoHS/Reach/WEEE/MSDS
