The SmartSolar MPPT RS solar charge controllers are Victron’s solution for systems with large series-connected PV arrays charging 48 V DC battery banks. This product is perfect for large off-grid, and grid-connected battery systems.

Available in a 5.76kW and 11.52kW model, features include a wide 80-450 VDC operating solar voltage input, independent tracking inputs, full connectivity, isolated PV connections, display screen, and fully programmable battery charging parameters and active cooling. The new metal case design and fully covered electrical connections improve the safety and modernize the presentation in line with the latest suite of Victron products.

MPPT: Ultra Fast Maximum Power Point Tracking

The SmartSolar RS solar charge controller connects to a PV array of between 80 and 450 Volt Voc and will efficiently charge your 48V battery bank with either 100A or 200A.

The charge settings are fully programmable and can be set up for different battery chemistries, like lead-acid, lithium, and more.

Setup and monitor with VictronConnect

The SmartSolar RS charge controller can be remotely controlled and configured over Bluetooth via the VictronConnect App. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, historical data and trends.

Daisy Chain Additional Units

The SmartSolar RS charge controller is equipped with VE.Can bus ports. This allows for communication with additional SmartSolar RS & VE.Can MPPT units. The additional units are simply “daisy-chained” to each other with an RJ45 cable.

When connected to each other, all individual charge controllers will synchronize their charge stages. They can also send their data, via the same cable, for monitoring to a GX device (such as the Cerbo GX).

Remote Monitoring and Control

If the GX device is connected to the internet, the Victron Remote Management Portal (VRM) provides access to the full power of your SmartSolar RS charge controllers.

If your installation is connected to a GX device and the internet, Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; for free.

For remote installations – even when there is no internet connection nearby – you may be able to monitor your MPPT by connecting the  GlobalLink 520.

SmartSolar Display

The SmartSolar RS charge controller is equipped with a display on the front panel. The display reads battery volts, charge current and voltages from both array’s individually including instantaneous and total figures and unit status including any possible error codes.

I/O Connections

The SmartSolar RS charge controller is equipped with a programmable relay and options for remote temperature and voltage sensing. The remote input can accept the Victron smallBMS and other types of BMS with allow-to-charge signals.

ATESS PV combiner box is an accessory for multiple PV strings connection, it is with smart controller inbuilt for monitoring, along with comprehensive protections including fuse and SPD.

Features:

• Lightning protection
• Optional string monitoring function
• RS485 communication interface
• Input fuse for over current protection
• IP65 environment compatibility
• Flexible design, 8,16 inputs optional

HP Spectre x360 2-in-1 Laptop 14-ef2017nia, Windows 11 Pro, 13.5″, touch screen, Intel® Core™ i5, 8GB RAM, 1TB SSD, WUXGA+, nightfall black

Key Features

• TR technology + Half Cell
  TR technology with Half-cell aims to eliminate the cell gap to increase module efficiency (mono-facial up to 21.38%)
• 9BB instead of 5BB
  9BB technology decreases the distance between bus bars and finger grid line which is benefit to power increase.
• Higher lifetime Power Yield
  2% first year degradation, 0.55% linear degradation
•  Best Warranty
  12-year product warranty, 25-year linear power warranty
• Enhanced Mechanical Load
  Certified to withstand wind load (2400 Pascal) and snow load (5400 Pascal).
•  Avoid debris, cracks and broken gate risk effectively
  9BB technology using circular ribbon that could avoid debris, cracks and broken gate risk effectively

Specification | STC

• Module Type: JKM480M-7RL3-V
• Maximum Power (Pmax): 480Wp
• Maximum Power Voltage (Vmp): 43.48V
• Maximum Power Current (Imp): 11.04A
• Open-circuit Voltage (Voc): 52.34V
• Short-circuit Current (Isc): 11.86A
• Module Efficiency STC (%): 21.38%
• Operating Temperature (℃): -40℃~+85℃
• Maximum system voltage: 1000/1500VDC (IEC)
• Maximum series fuse rating: 20A
• Power tolerance: 0~+3%
• Temperature coefficients of Pmax: -0.35%/℃
• Temperature coefficients of Voc: -0.28%/℃
• Temperature coefficients of Isc: 0.048%/℃
• Nominal operating cell temperature (NOCT): 45±2℃

Mechanical Characteristics

• Cell Type: P type Mono-crystalline
• No. of cells: 156 (2×78)
• Dimensions: 2182×1029×35mm (85.91×40.51×1.38 inch)
• Weight: 25.0kg (55.12 lbs)
• Front Glass: 3.2mm, Anti-Reflection Coating,
  High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminum Alloy
• Junction Box: IP68 Rated
• Output Cables: TUV 1×4.0mm2 (+): 250mm, (-): 150mm or Customized Length
