The Conext Automatic Generator Start (AGS) can automatically activate or stop a generator in response to changing power requirements. Excellent addition to an off-grid or backup power system, the AGS seamlessly connects to the Xanbus network and shares status information with all other devices on the network. It can monitor a set of system user-programmable parameters such as battery voltage, state of charge, or grid power and can activate the generator in response to any changes. The Conext AGS can also be configured remotely using the Insight energy management system to engage a generator and can assist an inverter/charger when output power demands are high.

Why Choose Conext Automatic Generator Start

Higher Return on Investment

• Integrate with an inverter/charger to maximize system power performance

Designed for Reliability

• Tested and qualified for harsh environmental conditions (HALT reliability testing)

Flexible

• Works with multiple Xanbus devices such as XW Pro, SW, MPPT 60-150, MPPT 80-600, MPPT 100-600, SCP, Insight
• User-programmable trigger settings to meet specific application needs such as battery voltage, exercise time, inverter AC power loads, SOC, and quiet time
• Supports manual start and stop operation modes

Easy to Service

• Access and troubleshoot AGS device events using the Insight or SCP
• Easily upgrade new firmware to the AGS using Insight

Easy to Install

• Wall mount
• RJ45 connections for Xanbus network cables

Mechanical Characteristics

• Solar Cell: Monocrystalline silicon 182 mm
• No. of Cells: 144 (6 × 24)
• Dimensions: 2278 × 1134 × 35 mm (89.7 × 44.6 × 1.4 inches)
• Weight: 27.5 kgs (60.6 lbs.)
• Front Glass: 3.2 mm (0.126 inches) fully tempered glass
• Output Cables: 4.0 mm2, (-) 350 mm (+) 160 mm in length or customized length
• Junction Box: IP68 rated (3 bypass diodes)
• Operating Module Temperature: -40 °C to +85 °C
• Maximum System Voltage: 1500 V DC (IEC)
• Maximum Series Fuse Rating: 25 A
• Power Tolerance: 0/+5 Wc

Electrical Characteristics

• Module Type: STP555S-C72/Vmh
• Testing Condition: STC
• Maximum Power (Pmax/W): 555
• Optimum Operating Voltage (Vmp/V): 42.24
• Optimum Operating Current (Imp/A): 13.14
• Open Circuit Voltage (Voc/V): 50.07
• Short Circuit Current (Isc/A): 14.07
• Module Efficiency (%): 21.5

Unmatched Power Output for Maximum Efficiency

The Canadian Solar 705 Watts TOPBiHiKu7 N-type Bifacial Module is designed to revolutionize solar energy production with its industry-leading power capacity. With a robust 705-watt output, this module ensures superior performance and reliability, making it an excellent choice for residential, commercial, and industrial solar installations. Whether you’re looking to lower your electricity bills or reduce your environmental footprint, this module delivers consistent, high-efficiency energy production to meet your needs.

Advanced N-type Bifacial Technology

At the heart of the Canadian Solar TOPBiHiKu7 is cutting-edge N-type bifacial technology that harnesses sunlight on both sides of the module. This innovation boosts light absorption and amplifies energy generation, even in low-light conditions. Ideal for installations in regions with varied sunlight exposure, this smart technology ensures optimal performance, making the module a reliable solution for diverse climates and terrains. Gain a competitive edge in energy production with a technology tailored for efficiency and longevity.

Durability and Sustainable Design

Built with premium materials and backed by Canadian Solar’s engineering expertise, the TOPBiHiKu7 module is engineered for durability and long-term reliability. Its robust construction resists environmental stressors such as wind, snow, and high temperatures, ensuring stable operation under challenging conditions. Moreover, the bifacial design aligns with sustainability goals, maximizing energy received while reducing waste. The module is perfect for those who value eco-conscious energy production without compromising performance.

• • Multifunctional

  Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally, it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple systems integration features such as three or split-phase operation and parallel operation.

  • Two AC Inputs & two AC Outputs

  The Quattro can be connected to two independent AC sources, for example, shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is life only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.

  • Unique PowerAssist feature

  The Quattro will prevent the overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shoreside supply with power taken from the battery.

  • Virtually unlimited power thanks to parallel operation

  Up to 6 Quattros can operate in parallel to achieve higher power output. Three-phase or split-phase operation is also possible. Please check our datasheets to see which models have parallel, three-phase, and split-phase capabilities.

  • Remote Monitoring and Control

  Monitor and control your Quattro and system or systems locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Quattro to setting a Geofence for-hire vehicles and more…
