The CL 30/33/50 are the ideal solar solution for commercial and industrial buildings, carports. Scalable and flexible PV architecture together with Schneider Electric’s broad range of low voltage products makes CL range the ideal choice for commercial and industrial buildings.

Optimum System Performance

• Input for 3 MPPTs for the CL 30/33 and 5 MPPTs for CL 50
• 98.7% Peak Efficiency
• DC/AC ratio up to 1.5
• DC/AC surge protection

Flexible

• Compatible with Insight for easier remote asset management and troubleshooting.

Easy to Install

• Low weight to allow for easy installation.
• Broad range of Schneider Electric LV products for a complete solution
• AC coupling compatible with Schneider Electric CIB storage products.

Compatible with Insight

• Setup and configuration
• Remote monitoring & control with advanced data security
• Web and mobile app
• Multi-site management for installers and portfolio managers

One system. Many options. For your individual needs

In combination with the Sunny Portal powered by ennexOS, the Data Manager M enables monitoring, management, and grid-compliant power control in decentralized PV systems. Thanks to flexible expansion options, the Data Manager M is already well-equipped for business models in the energy market of the future. The Data Manager M is the ideal professional system interface for electric utility companies, direct sellers, service technicians, and PV system operators.

Coordinated user interfaces and intuitive assistance functions to simplify operation, parameterization, and commissioning. Both variants are modularly expandable with many additional functions and interfaces.

Professional monitoring and control for decentralized energy systems up to the megawatt range

The Data Manager M is the perfect monitoring and control solution for decentralized large-scale PV power plants up to 2.5 MVA with up to 50 devices. Thanks to the RS485 and Ethernet interfaces as well as analog and digital input and output systems, users benefit from particularly versatile connection options. The Data Manager M is the professional system interface for electric utility companies, direct sellers, service technicians, and PV system operators.

ATESS Slave Battery Rack BR114RPB

The latest, most advanced features on the industry’s most trusted and proven platform—that’s the essence of OutBack’s new FXR Series of Grid/Hybrid inverter/chargers. Capable of off-grid or grid-connected operation in a single model, the FXR Grid/Hybrid inverter/chargers provide system designers with unprecedented flexibility and compatibility for nearly any power conversion scenario.

The new FXR features and technologies on the acclaimed FX platform include:

• Both off-grid and grid-tied functionality in one unit
• Seven programmable modes, including GridZero and Support Mode and built-in networked communications
• Advanced Battery Charging (ABC) with expanded charging voltages and time parameters, enabling system designers to accommodate the specific charging profiles and algorithms of new and emerging energy storage technologies including Lithium Ion, Aqueous Ion and Flow chemistry batteries
•  Easy system upgradability in the field

FXR inverter/chargers can be paired with a MATE3s remote to add OPTICS RE to remotely monitor and control system performance from any location. Available in power ranges from 2000W-3600W, multiple units may be stacked and connected with other OutBack Power electronics for more seamless system integration and the ability to function in a wide variety of applications, and system sizes. Up to nine inverters can be combined in a 3-phase system with the 12V, 24V or 48V models, and up to 36kW in a grid-tied 24V or 48V system. The exclusive modular system architecture means that increased power output is just an additional FXR inverter/charger away.

Available in sealed or vented units with NEMA type 1 die-cast aluminum chassis designed to operate in the harshest environmental conditions such as high temperatures, humidity or corrosive salt air, the FXR’s continue in OutBack’s tradition of absolute dependability in mission critical installations no matter how harsh or challenging the conditions.

Features:

•  Dimensions (LxWxH): 16.25 × 8.25 × 12 inches
•  Weight: 28 kg
•  Single-phase, 230V Sinewave Output
•  Programmable for Seven Different Modes with Generator Assist
•  Modular, Stackable Design for up to Nine Inverters in Three-phase and 10 Inverters in Grid-tied
•  Up to 93% Operating Efficiency
•  Field Upgradable Software
•  Standard 5-Year Warranty with Optional 10-Year Upgrade
