• • Multifunctional

  Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally, it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple systems integration features such as three or split-phase operation and parallel operation.

  • Two AC Inputs & two AC Outputs

  The Quattro can be connected to two independent AC sources, for example, shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is life only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.

  • Unique PowerAssist feature

  The Quattro will prevent the overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shoreside supply with power taken from the battery.

  • Virtually unlimited power thanks to parallel operation

  Up to 6 Quattros can operate in parallel to achieve higher power output. Three-phase or split-phase operation is also possible. Please check our datasheets to see which models have parallel, three-phase, and split-phase capabilities.

  • Remote Monitoring and Control

  Monitor and control your Quattro and system or systems locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Quattro to setting a Geofence for-hire vehicles and more…

The HT 1100 Vdc Series 73-120 kW is GoodWe’s new string inverter for C&I and small utility projects to boost your power and profit. Generate your solar power and make use of it with this centerpiece of the clean energy system. The HT Series seamlessly incorporates its technical strengths designed to achieve higher savings in the installation, enhance productivity with increased energy yields, realize high power density and diversify available monitoring options. It takes safety to the top possible level in accordance with the strictest industry standards and runs efficiently even under the harshest environmental conditions. This unrivalled set of features was conceived to ensure the lowest levelized cost of electricity (LCOE) to offer this ideal choice for commercial and industrial PV systems.

MORE POWER

• Module efficiency up to 22.5 %
• Up to 4.5 % lower LCOE
• Up to 5.6 % lower system cost
• Comprehensive LID / LeTID mitigation technology, up to 50% lower degradation
• Compatible with mainstream trackers, cost-effective product for utility power plant
• Better shading tolerance

MORE RELIABLE

• Minimizes micro-crack impacts
• 40 °C lower hot spot temperature, greatly reduce module failure rate
• Heavy snow load up to 5400 Pa, enhanced wind load up to 2400 Pa
• 12 years Enhanced Product Warranty on Materials and Workmanship
• 25 years Linear Power Performance Warranty

ELECTRICAL DATA | STC

• Nominal Max. Power (Pmax): 560 W
• Opt. Operating Voltage (Vmp): 42.3 V
• Opt. Operating Current (Imp): 13.24 A
• Open Circuit Voltage (Voc): 51.4 V
• Short Circuit Current (Isc): 13.69 A
• Module Efficiency: 21.7%
• Operating Temperature: -40°C ~ +85°C
• Max. System Voltage: 1500V (IEC/UL) or 1000V (IEC/UL)
• Module Fire Performance: TYPE 1 (UL 61730 1500V) or TYPE 2 (UL 61730 1000V) or CLASS C (IEC 61730)
• Max. Series Fuse Rating: 25 A
• Application Classification: Class A
• Power Tolerance: 0 ~ + 10 W

MECHANICAL DATA

• Cell Type: Mono-crystalline
• Cell Arrangement: 144 [2 x (12 x 6)]
• Dimensions: 2278 ˣ 1134 ˣ 30 mm (89.7 ˣ 44.6 ˣ 1.18 in)
• Weight: 27.6 kg (60.8 lbs)
• Front Cover: 3.2 mm tempered glass
• Frame: Anodized aluminium alloy
• J-Box: IP68, 3 bypass diodes
• Cable: 4 mm2 (IEC), 12 AWG (UL)
• Cable Length (Including Connector): 410 mm (16.1 in) (+) / 290 mm (11.4 in) (-) (supply additional jumper cable: 2 lines / Pallet) or customized length
• Connector: T4 series or H4 UTX or MC4-EVO2

Why choose Growatt SPF 5000 ES Off-Grid Inverter?

Monitoring: The system can also be remotely monitored using a WiFi or GPRS dongle. Parallel scaling is supported.

Charge controller: The MPPT charge controller lowers the voltage of panels to the required level to charge the battery. The current is raised with the same ratio as the voltage is lowered.

This continuously happens during the day to optimize the use of energy. This is dependent on the power of the sun, the angle, and the temperature and health of the panels.

The charge controller also makes sure the battery will not be overcharged, but also not fully discharged.

Capacity expansion: The system’s capacity can be expanded up to 30kW by combining a total of six of these units in parallel operation.
