African Energy modules are made by some of the world’s most sophisticated module manufacturers and are designed for Africa’s off-grid solar charging and water pumping needs. The modules include efficient crystalline cells set in a solid aluminum frame and feature TÜV and IEC certification. With a 30-year warranty, these modules can provide power for several generations – and the quality is assured by African Energy’s decade of experience in the solar industry.

Electrical Characteristics:

• Maximum Power at STC (Pmax) 620 W
• Optimum Operating Voltage (Vmp) 40.93 V
• Optimum Operating Current (Imp) 12.90 A
• Open Circuit Voltage (Voc) 48.40 V
• Short Circuit Current (Isc) 13.70 A
• Module Efficiency 22.95%
• Operating Module Temperature -40 °C to +85 °C
• Maximum System Voltage 1000/1500 V DC (IEC)
• Maximum Series Fuse Rating 20 A
• Power Tolerance 0/+5 %
• 30-year warranty

Mechanical Specifications:

• Solar Cells Monocrystalline 144 (72*2) pcs
• No. of Cells 144 (72*2)
• Dimensions 2278x1134x30mm
• Weight 28.3kg
• Front Glass High transparency solar glass 3.2mm
• Frame Black/Silver Anodized aluminum alloy
• Junction Box IP68 rated
• Output Cables 4.0 mm2, portrait: 300mm/300mm
• Connector MC4 Compatible
• Wind/Snow Load 2400pa/5400pa

The LV-HUB is a CAN communication Combiner and can be used to connect multiple master CAN communication addresses from multiple clusters that compose an LV system.

The LV-HUB-XP is not a power device LV-HUB-XP minimum startup voltage is 30 Vdc and max Input voltage is 60Vdc LV HUB-XP max current is 2A and it is equipped with built in fuse rated 5A.

The Deye BOS-G series is a state-of-the-art LiFePO4 battery system designed to provide reliable, safe, and efficient energy storage for your home or business. With a wide range of configurations and capacities, the BOS-G series offers a versatile solution to meet your specific energy needs.

The BOS-G series utilizes advanced LiFePO4 cell technology, known for its superior thermal stability, high cycle life, and excellent safety profile. Each battery module has a nominal capacity of 100Ah and energy of 5.12 kWh, allowing you to scale your system to perfectly match your energy storage requirements.

With a recommended depth of discharge (DOD) of 90% and a cycle life of ≥6000 cycles at 25°C, the BOS-G series ensures maximum usable energy and long-term performance. The system also features a wide operating temperature range of -20°C to 55°C, making it suitable for various environments.

The BOS-G series comes equipped with a high-voltage box (HVB750V/100A) that enables seamless integration with your existing power system. The high-voltage box supports an operating voltage range of 120-750 Vdc and a maximum charge/discharge current of 125A, ensuring efficient power transfer and compatibility with a wide array of inverters and chargers.

Safety is a top priority with the BOS-G series. The system features multiple layers of protection, including over-voltage, under-voltage, over-current, short-circuit, and temperature monitoring. The IP20-rated enclosure provides protection against dust and debris, while the built-in status indicators keep you informed of the system’s operating status at all times.

Deye’s commitment to quality and customer satisfaction is evident in the 10-year warranty provided with the BOS-G series. With its robust design, advanced features, and exceptional performance, the Deye BOS-G LiFePO4 battery system is the ideal choice for those seeking a reliable and efficient energy storage solution.

The connection between BMU and Battery-Box should be the Straight-Through Wired Cable (CAT 5 shield or above, not longer than 10m).

Detailed connection instructions with inverters could be read in the Battery-Box LVS/LVL Quick Start Guide.

Properties:

•  Protection rating: IP55
•  Communication: Ethernet / CAN / RS485
•  Input voltage: 40-60V (Supply by Battery-Box through network cable)
•  Input current: 200mA
•  Dimensions (L/W/H): 222x154x5
