UP5000 is a new battery in the UP series from Pylontech. The UP5000 is a 48V battery with incredible features to provide a competitive edge in the market.

Key Features

• Modular design for ease of expansion
• Higher usable capacity resulting in fewer battery modules installed
• Usable capacity up to 4,560Wh
• Parallel Capability of up to 16 units
• Allows for large installation of up to 72.96kWh with no LV Hub
• Intelligent BMS protecting battery cells
• 95% DoD with more usable capacity
• RS485 and CAN compatible

The HT 1100 Vdc Series 73-120 kW is GoodWe’s new string inverter for C&I and small utility projects to boost your power and profit. Generate your solar power and make use of it with this centerpiece of the clean energy system. The HT Series seamlessly incorporates its technical strengths designed to achieve higher savings in the installation, enhance productivity with increased energy yields, realize high power density and diversify available monitoring options. It takes safety to the top possible level in accordance with the strictest industry standards and runs efficiently even under the harshest environmental conditions. This unrivalled set of features was conceived to ensure the lowest levelized cost of electricity (LCOE) to offer this ideal choice for commercial and industrial PV systems.

The Conext MPPT 80 600 solar charge controller offers an industry-first set of integration features and top performance that allows for large PV array systems to be easily installed and connected to the battery bank at the lowest overall cost. Installing one MPPT 80 600 is faster than installing multiple smaller charge controllers and lowers overall costs further by utilizing fewer PV strings, smaller wiring and conduit, and by eliminating the need for PV combiner boxes and DC circuits breakers.

Why Choose Conext MPPT 80 600 Charge Controller

Higher return on investment

• Installs faster with fewer costly components
• Improve battery life with selectable multi-stage temperature compensated charging
• Harvest more energy with shade tolerant fast sweep MPPT algorithm

Flexible

• Remote monitoring available
• Compatible with any brand of PV module, any grounding method
• Stand-alone application or full integration with Conext XW Pro or XW+ inverter charger system

Designed for reliability

• Robust design through rigorous Multiple Environmental Over Stress Testing (MEOST)

Easy to install

• Fewer string wires
• Smaller AWG Wire
• No need for combiner box or GFI circuit breaker

Key Features

• N-type TechnologyN-type modules with Tunnel Oxide Passivating Contacts (TOPcon) technology offer lower LID/LeTID degradation and better low light
  performance.
• HOT 3.0 TechnologyN-type modules with Jinko Solar’s HOT 3.0 technology offer better reliability and efficiency.
• Durability Against Extreme EnvironmentHigh salt mist and ammonia resistance.
• Mechanical Load EnhancedCertified to withstand:
  5400 Pa front side max static test load
  2400 Pa rear side max static test load.
• SMBB TechnologyBetter light trapping and current collection to improve module power output and reliability.
• Anti-PID GuaranteeMinimizes the chance of degradation caused by PID phenomena through optimization of cell production technology and material
  control.

Specification | STC

• Module Type: JKM615N-66HL4M-V
• Maximum Power (Pmax): 615Wp
• Maximum Power Voltage (Vmp): 40.73V
• Maximum Power Current (Imp): 15.10A
• Open-circuit Voltage (Voc): 48.79V
• Short-circuit Current (Isc): 16.08A
• Module Efficiency STC (%): 22.77%
• Temperature Coefficients of Pmax: -0.29 %/°C
• Temperature Coefficients of Voc: -0.25 %/°C
• Temperature Coefficients of Isc: 0.045 %/°C
• Power tolerance: 0~+3%
• Operating Temperature: -40 °C ~ +70°C
• Maximum System Voltage: 1000/1500 VDC (IEC)
• Maximum Series Fuse Rating: 30 A

Mechanical Characteristics

• Cell Type: N -type Mono-crystalline
• No. of cells: 132 (66×2)
• Dimensions: 2382×1134×35 mm
• Weight: 28.2 kg
• Front Glass: 3.2mm, Anti-reflection Coating, High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminum Alloy
• Junction Box: IP68 Rated
• Protection Class: Class II
• IEC Fire Type: Class C
• Connector Type: K03M/MC4/Others
• Output Cables: 4.0 mm2 (+): 400 mm, (-): 200 mm or Customized Length
