Introducing the S6-EH3P50K-H Series. High voltage, three-phase energy storage for commercial applications. The inverter series, which boasts a maximum charge/discharge current of 70A+70A across two independently controlled battery ports, has four integrated MPPTs with a string current capacity of up to 20A – ensuring unmatched power delivery. Whether for on or off-grid applications, the S6-EH3P50K-H series supports parallel operation of up to six units, with a backup port capable of supporting 1.6 times overload for short durations. This latest range is compatible with an array of batteries, thanks to its wide voltage range, and offers peak shaving control in both “self-use” and “generator” modes.

Three-Phase High Voltage Energy Storage Inverter

Leading Features

• 2 seconds of 160% overload capability
• Supports peak shaving features in “self-use” and “generator” modes
• Supports Unbalanced and Half-Wave Loads on both the Grid and Backup Port
• Supports 200% DC/AC ratio and makes full use of PV charging, providing a long backup
• Supports a maximum input current of 20A, making it ideal for all high-power PV modules of any brand
• Real-time battery monitoring, remote upgrade, and battery healing function to prolong battery life
• A wide battery voltage range accommodates the prevalent high-voltage lithium batteries found in the market
• Battery charging/discharging current 140A/70A+70A, suitable for 280Ah cell standard 0.5C application condition

The HUB system communications manager is the backbone of your networked OutBack power conversion system. The OutBack HUB communicates stacking; load share and power save on/off signals. Interconnection cabling is standard Ethernet CAT5 with RJ45 modular jacks. Through the use of a HUB, your system is completely coordinated and managed by the MATE.

The latest, most advanced features on the industry’s most trusted and proven platform—that’s the essence of OutBack’s new FXR Series of Grid/Hybrid inverter/chargers. Capable of off-grid or grid-connected operation in a single model, the FXR Grid/Hybrid inverter/chargers provide system designers with unprecedented flexibility and compatibility for nearly any power conversion scenario.

The new FXR features and technologies on the acclaimed FX platform include:

• Both off-grid and grid-tied functionality in one unit
• Seven programmable modes, including GridZero and Support Mode and built-in networked communications
• Advanced Battery Charging (ABC) with expanded charging voltages and time parameters, enabling system designers to accommodate the specific charging profiles and algorithms of new and emerging energy storage technologies including Lithium Ion, Aqueous Ion and Flow chemistry batteries
•  Easy system upgradability in the field

FXR inverter/chargers can be paired with a MATE3s remote to add OPTICS RE to remotely monitor and control system performance from any location. Available in power ranges from 2000W-3600W, multiple units may be stacked and connected with other OutBack Power electronics for more seamless system integration and the ability to function in a wide variety of applications, and system sizes. Up to nine inverters can be combined in a 3-phase system with the 12V, 24V or 48V models, and up to 36kW in a grid-tied 24V or 48V system. The exclusive modular system architecture means that increased power output is just an additional FXR inverter/charger away.

Available in sealed or vented units with NEMA type 1 die-cast aluminum chassis designed to operate in the harshest environmental conditions such as high temperatures, humidity or corrosive salt air, the FXR’s continue in OutBack’s tradition of absolute dependability in mission critical installations no matter how harsh or challenging the conditions.

Features:

•  Dimensions (LxWxH): 16.25 × 8.25 × 12 inches
•  Weight: 28 kg
•  Single-phase, 230V Sinewave Output
•  Programmable for Seven Different Modes with Generator Assist
•  Modular, Stackable Design for up to Nine Inverters in Three-phase and 10 Inverters in Grid-tied
•  Up to 93% Operating Efficiency
•  Field Upgradable Software
•  Standard 5-Year Warranty with Optional 10-Year Upgrade
