Conext Battery Monitor indicates hours of battery-based runtime and determines battery bank state of charge. Conext Battery Monitor shares key battery bank parameters with Conext XW Pro or XW+ inverter/chargers improving the overall system performance of 24V and 48V battery banks. Detecting battery string imbalance is determined using innovative mid-point sensing technology providing time to address the issue before performance is significantly impacted.

Why Choose Conext Battery Monitor

Higher Return on Investment

• Get the most out of battery based Conext inverter/charger systems
• Cleary understand hours of available battery based autonomy
• Detect imbalance between battery-strings before it becomes an issue

Designed for Reliability

• Extensive quality and reliability testing
• Highly Accelerated Life Testing (HALT)

Flexible

• Stand-alone application or integration with Conext XW Pro or XW+ inverter/charger systems
• Enables State of Charge triggers for AGS module control of diesel generators
• Enables balancing of multi-battery bank systems for large clustered Conext XW+ inverter charger systems

Easy to Service

• Remotely monitor, troubleshoot or upgrade firmware with InsightHome, InsightFacility
• Built-in data logger

Easy to Install

• Wall-mount, DIN-rail mount, panel mount
• RJ45 connections for XanBus network and battery signals
• Configure with front-panel buttons, InsightHome, InsightFacility or RS485 Modbus

Higher yields / Safe & Reliable / Smart / User-friendly

SUN-20K-SG05LP3-EU-SM2 is a brand new three-phase hybrid inverter with a low-voltage battery, ensuring the system is safe and reliable. With a compact design and high-power density, this series supports a 1.3 DC/AC ratio, saving device investment. It supports a three-phase unbalanced output, extending the application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remote control, and x1 DRM port, which makes the system smart and flexible.

It is equipped with RS485 / CAN port for battery communication.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely, which makes PV plant O&M easier.

Key Features

• 100% unbalanced output, each phase; Max. output up to 50% rated power
• AC couple to retrofit existing solar system
• Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
• Max. charging/discharging current of 350A
• Support storing energy from diesel generator
• 48V low voltage battery, transformer isolation design
• 6 time periods for battery charging/discharging

Technical Specifications

African Energy modules are made by some of the world’s most sophisticated module manufacturers and are designed for Africa’s off-grid solar charging and water pumping needs. The modules include efficient crystalline cells set in a solid aluminum frame and feature TÜV and IEC certification. With a 30-year warranty, these modules can provide power for several generations – and the quality is assured by African Energy’s decade of experience in the solar industry.

Electrical Characteristics:

• Maximum Power at STC (Pmax) 620 W
• Optimum Operating Voltage (Vmp) 40.93 V
• Optimum Operating Current (Imp) 12.90 A
• Open Circuit Voltage (Voc) 48.40 V
• Short Circuit Current (Isc) 13.70 A
• Module Efficiency 22.95%
• Operating Module Temperature -40 °C to +85 °C
• Maximum System Voltage 1000/1500 V DC (IEC)
• Maximum Series Fuse Rating 20 A
• Power Tolerance 0/+5 %
• 30-year warranty

Mechanical Specifications:

• Solar Cells Monocrystalline 144 (72*2) pcs
• No. of Cells 144 (72*2)
• Dimensions 2278x1134x30mm
• Weight 28.3kg
• Front Glass High transparency solar glass 3.2mm
• Frame Black/Silver Anodized aluminum alloy
• Junction Box IP68 rated
• Output Cables 4.0 mm2, portrait: 300mm/300mm
• Connector MC4 Compatible
• Wind/Snow Load 2400pa/5400pa

The BYD Battery-Box LV Flex is a lithium iron phosphate (LFP) battery pack for use with an external inverter. The communication with the inverter is established through the Battery-Box Premium LV BMU (Battery Management Unit). Connect up to 64 LV Flex Modules in parallel on one BMU to reach individual capacities between 5 and 320 kWh. Thanks to it´s 3U design, the LV Flex can adapt to off-the-shelf racking systems. And with the possibility of stacking up to 4 units or installing them vertically, the LV Flex provides a variety of options for bespoke housing designs.

KEY FEATURES

• Perfect Battery for bespoke Projects and Integrated Systems
• Scalable from 5 kWh to 320 kWh
• Maximum Flexibility for any Application with up to 64 Modules connected in Parallel
• Compatible with Market Leading 1 and 3 Phase Inverters
• Cobalt Free Lithium Iron Phosphate (LFP) Battery: Maximum Safety, Lifespan and Power
• Capable of High-Powered Emergency-Backup and Off-Grid Function
• Self-Consumption Optimization for Residential and
  Commercial Applications

TECHNICAL PARAMETERS

• Usable Energy 5.0 kWh
• Max Cont. Output Current 70 A
• Peak Output Current 105 A, 5 s
• Dimensions (H/W/D) 132x 482 x 525 mm
• Weight 47 kg
• Nominal Voltage 51.2 V
• Operating Voltage 43.2 -57.6 V
• Operating Temperature -10 °C to +50°C
• Battery Cell Technology Lithium Iron Phosphate (cobalt-free)
• Communication CAN/RS485
• Enclosure Protection Rating IP20
• Round-trip Efficiency ≥95%
• Scalability Max. 64 in Parallel (320 kWh)
• Certification IEC62619 / CE / CEC / UN38.3 / IEC62040
• Applications ON Grid / ON Grid + Backup / OFF Grid
• Compatible Inverters Refer to BYD Battery-Box LV Flex Minimum Configuration List
• Installation method With / Without Rack
