Higher yields / Safe & Reliable / Smart / User-friendly

SUN-50K-SG01HP3-EU-BM4 is a brand new three-phase hybrid inverter with a high-voltage battery, ensuring the system is safe and reliable. With a compact design and high-power density, this series supports a 1.3 DC/AC ratio, saving device investment. It supports a three-phase unbalanced output, extending the application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remote control, and x1 DRM port, which makes the system smart and flexible.

It is equipped with RS485 / CAN port for battery communication.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely, which makes PV plant O&M easier.

• 100% unbalanced output, each phase; Max. output up to 50% rated power
• DC coupled and AC coupled to retrofit existing solar system.
• Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
• Max. charging/discharging current of 100A
• High voltage battery, higher efficiency
• 6 time periods for battery charging/discharging
• Support storing energy from diesel generators.

Technical Specifications

The Conext MPPT 80 600 solar charge controller offers an industry-first set of integration features and top performance that allows for large PV array systems to be easily installed and connected to the battery bank at the lowest overall cost. Installing one MPPT 80 600 is faster than installing multiple smaller charge controllers and lowers overall costs further by utilizing fewer PV strings, smaller wiring and conduit, and by eliminating the need for PV combiner boxes and DC circuits breakers.

Why Choose Conext MPPT 80 600 Charge Controller

Higher return on investment

• Installs faster with fewer costly components
• Improve battery life with selectable multi-stage temperature compensated charging
• Harvest more energy with shade tolerant fast sweep MPPT algorithm

Flexible

• Remote monitoring available
• Compatible with any brand of PV module, any grounding method
• Stand-alone application or full integration with Conext XW Pro or XW+ inverter charger system

Designed for reliability

• Robust design through rigorous Multiple Environmental Over Stress Testing (MEOST)

Easy to install

• Fewer string wires
• Smaller AWG Wire
• No need for combiner box or GFI circuit breaker

The LV-HUB is a CAN communication Combiner and can be used to connect multiple master CAN communication addresses from multiple clusters that compose an LV system.

The LV-HUB-XP is not a power device LV-HUB-XP minimum startup voltage is 30 Vdc and max Input voltage is 60Vdc LV HUB-XP max current is 2A and it is equipped with built in fuse rated 5A.

Specification | STC

• Module Type: JKM550N-72HL4-V
• Maximum Power (Pmax): 550Wp
• Maximum Power Voltage (Vmp): 41.64V
• Maximum Power Current (Imp): 13.33A
• Open-circuit Voltage (Voc): 50.34V
• Short-circuit Current (Isc): 14.07A
• Module Efficiency STC (%): 21.48%
• Operating Temperature (℃): -40℃~+85℃
• Maximum system voltage: 1000/1500VDC (IEC)
• Maximum series fuse rating: 25A
• Power tolerance: 0~+3%
• Temperature coefficients of Pmax: -0.35%/℃
• Temperature coefficients of Voc: -0.28%/℃
• Temperature coefficients of Isc: 0.048%/℃
• Nominal operating cell temperature (NOCT): 45±2℃

Mechanical Characteristics

• Cell Type: N type Mono-crystalline
• No. of cells: 144 (6×24)
• Dimensions: 2278×1134×35mm (89.69×44.65×1.38 inch)
• Weight: 28.9 kg (61.73 lbs)
• Front Glass: 3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass
• Frame: Anodized Aluminium Alloy
• Junction Box: IP68 Rated
• Output Cables: TUV 1×4.0mm2 (+): 400mm , (-): 200mm or Customized Length
