African Energy 620 Watts N-Type TOPCon Bifacial Solar Module

African Energy 620 Watts N-Type TOPCon Bifacial Solar Module

(0)

₦146,625.00

African Energy modules are made by some of the world’s most sophisticated module manufacturers and are designed for Africa’s off-grid solar charging and water pumping needs. The modules include efficient crystalline cells set in a solid aluminum frame and feature TÜV and IEC certification. With a 30-year warranty, these modules can provide power for several generations – and the quality is assured by African Energy’s decade of experience in the solar industry.

Quantity:

Free Delivery

Nationwide shipping

Warranty

Manufacturer guarantee

Expert Support

Installation & maintenance

  • Description
  • Features
  • Specifications
  • Reviews

Description

African Energy modules are made by some of the world’s most sophisticated module manufacturers and are designed for Africa’s off-grid solar charging and water pumping needs. The modules include efficient crystalline cells set in a solid aluminum frame and feature TÜV and IEC certification. With a 30-year warranty, these modules can provide power for several generations – and the quality is assured by African Energy’s decade of experience in the solar industry.

Electrical Characteristics:

  • Maximum Power at STC (Pmax) 620 W
  • Optimum Operating Voltage (Vmp) 40.93 V
  • Optimum Operating Current (Imp) 12.90 A
  • Open Circuit Voltage (Voc) 48.40 V
  • Short Circuit Current (Isc) 13.70 A
  • Module Efficiency 22.95%
  • Operating Module Temperature -40 °C to +85 °C
  • Maximum System Voltage 1000/1500 V DC (IEC)
  • Maximum Series Fuse Rating 20 A
  • Power Tolerance 0/+5 %
  • 30-year warranty

Mechanical Specifications:

  • Solar Cells Monocrystalline 144 (72*2) pcs
  • No. of Cells 144 (72*2)
  • Dimensions 2278x1134x30mm
  • Weight 28.3kg
  • Front Glass High transparency solar glass 3.2mm
  • Frame Black/Silver Anodized aluminum alloy
  • Junction Box IP68 rated
  • Output Cables 4.0 mm2, portrait: 300mm/300mm
  • Connector MC4 Compatible
  • Wind/Snow Load 2400pa/5400pa

Key Features

No features available for this product.

Technical Specifications

No specifications available for this product.
